Suzuki GSX-R750G (1987) FUEL TANK (MODEL G) Diagram

#

Description
Price

1

NO DESCRIPTION AVAILABLE | OTHER THAN CALIFORNIA This part replaces 44100-28A10-7GF.

44110-06BV0-13L

Unavailable

1

(CA)TANK ASSY, FUEL | CALIFORNIA ONLY

44100-28A00-7GF

Unavailable

1

NO DESCRIPTION AVAILABLE | OTHER THAN CALIFORNIA This part replaces 44100-28A10-7JK.

44110-06BV0-13L

Unavailable

1

(CA)TANK ASSY, FUEL | CALIFORNIA ONLY; Includes Item(s) 2 - 3

44100-28A00-7JK

Unavailable

2

TAPE SET, FUEL TANK | FOR 7GF

68110-28A01-7UC

Unavailable

2

TAPE SET, FUEL TANK | FOR 7JK

68110-28A01-7VE

Unavailable

3

EMBLEM | FOR 7GF

68111-27A00-7TW

Unavailable

3

EMBLEM | FOR 7JK

68111-27A00-7JS

Unavailable

4

CAP SET, FUEL T This part replaces 44200-20A00-KEY.

44200-20841

Unavailable

5

PLUG, BREATHER | OTHER THAN CALIFORNIA This part replaces 44240-40A00.

44240-06B10

$38.33

6

GASKET | OTHER THAN CALIFORNIA

09168-12012

$1.83

7

VALVE, FUEL TANK BREATHER | CALIFORNIA ONLY This part replaces 44240-28A00.

44240-28A01

Unavailable

8

(CA)GASKET | CALIFORNIA ONLY

09168-27001

Unavailable

9

HOSE This part replaces 09343-05165.

09352-50005-00B

$13.93

10

MOLDING This part replaces 68241-27A00.

68241-04X50-00B

$27.30

11

CUSHION, FUEL TANK FRONT

44511-27A10

Unavailable

12

CUSHION, FUEL TANK SIDE

44545-27A10

Unavailable

13

BRACKET, REAR

45211-27A00

Unavailable

14

CUSHION, REAR

09320-14017

$2.35

15

CUSHION, REAR

09320-10038

$2.61

16

SPACER This part replaces 09180-06072.

09180-06271

$2.35

17

BOLT, GEAR SHIFT LINK This part replaces 01107-06205.

01500-0620A

$1.78

18

LOCK WASHER This part replaces 08321-21064.

08321-0106A

$1.84

19

.WASHER This part replaces 08322-21064.

08322-0106B

$2.26

20

WASHER, 6.5X24X1.6 This part replaces 09160-06072.

09160-06501

$1.86

21

BOLT This part replaces 01107-06356.

01500-0635A

$2.19

22

WASHER This part replaces 09160-12004.

09160-12088

$2.00

23

BOLT, REAR UPPER

09138-06038

Unavailable

24

BRACKET, FUEL TANK FRONT

44521-27A00

Unavailable

25

HOSE This part replaces 09343-05165.

09352-50005-00B

$13.93

26

HEAT SHEILD,FRM This part replaces 44191-27A00.

47166-03D00

$23.76

27

NO DESCRIPTION AVAILABLE This part replaces 44192-27A00.

44192-27A01

Unavailable

28

HEAT SHIELD, FUEL TANK LOWER

44194-06B00

Unavailable

29

SCREW

02142-06207

$1.49

30

WASHER This part replaces 09160-06007.

09160-06084

$1.78

31

HEAT SHIELD, AIR CLEANER

44193-27A02

Unavailable
