Suzuki GSX-R750G (1987) CRANKCASE COVER Diagram

#

Description
Price

1

COVER, CLUTCH (BLACK) | Includes Item(s) 2 This part replaces 11340-27A00.

11340-20C00

Unavailable

2

LENS, OIL LEVEL

11971-33210

$16.66

3

GASKET, CLUTCH COVER This part replaces 11482-27A01.

11482-27A20

$13.01

4

PIN

04211-09189

$1.64

5

GASKET

09168-06024

$2.19

6

BOLT This part replaces 07110-06255.

07130-0625B

$2.80

7

BOLT This part replaces 07110-06305.

07130-0630B

$3.04

8

BOLT This part replaces 07110-06355.

07130-0635B

$3.04

9

.PLUG This part replaces 09259-20012.

09259-20008-XC0

$6.76

10

O RING

09280-17003

$1.64

11

COVER,SIGNAL GE | ~E.NO.117381TO 11381-27A01 This part replaces 11381-27A00.

11381-27A03

Unavailable

11

COVER,SIGNAL GE | E.NO.117382~ This part replaces 11381-27A01.

11381-27A03

Unavailable

12

GASKET This part replaces 11491-27A00.

11491-27A30

$7.69

13

BOLT,6X23 This part replaces 09106-06059.

09106-06059-XC0

Unavailable

14

GASKET

09168-06024

$2.19

15

COVER, STARTER GEAR

11351-27A01

Unavailable

16

GASKET, GEAR COVER This part replaces 11483-27A00.

11483-27A20

$10.24

17

PIN (11X20) This part replaces 09206-11005.

09206-11017

$6.85

18

BOLT This part replaces 07110-06255.

07130-0625B

$2.80

19

BOLT, STATOR This part replaces 07110-06405.

07130-0640B

$3.10

20

GASKET

09168-06024

$2.19

21

NO DESCRIPTION AVAILABLE This part replaces 11361-27A00.

11361-27A02

Unavailable

22

PIN

04211-09129

$1.64

23

BOLT, STATOR This part replaces 07110-06405.

07130-0640B

$3.10

24

BOLT This part replaces 07110-06305.

07130-0630B

$3.04

25

BOLT This part replaces 07110-06505.

07130-0650B

$4.45

26

BOLT This part replaces 07110-06655.

07130-0665B

$3.47

27

BOLT This part replaces 07110-06705.

07130-0670B

$3.52
