Suzuki GSX-R750G (1987) COWLING (MODEL G) Diagram

#

Description
Price

1

NO DESCRIPTION AVAILABLE This part replaces 94400-27A40-7GF.

94400-27820-7GF

Unavailable

1

NO DESCRIPTION AVAILABLE | Includes Item(s) 2 - 5 This part replaces 94400-27A40-7JK.

94400-27820-7JK

Unavailable

2

TAPE SET | FOR 7GF

68190-27A11-7UC

Unavailable

2

TAPE SET | FOR 7JK

68190-27A11-7VE

Unavailable

3

EMBLEM This part replaces 68271-04A00-742.

68271-04A10-742

Unavailable

4

COVER, FRONT (BLACK)

94435-27A00-291

Unavailable

5

SCREW (4x12) This part replaces 03541-04125.

03541-0412A

$1.49

6

WINDOW, COWLING This part replaces 94611-06B01.

94611-27A01

Unavailable

7

MOLDING This part replaces 94631-27A00.

94631-49300

$18.86

8

SCREW

09139-05025

$2.05

9

SCREW, REAR

09139-05032

$1.89

10

NUT This part replaces 94619-27A00.

09159-05048

$7.22

11

PLATE, MIRROR RH

94529-27A00

Unavailable

12

PLATE, MIRROR LH

94539-27A00

Unavailable

13

NO DESCRIPTION AVAILABLE | FOR 7GF This part replaces 94430-27A50-14L.

94430-27A30

Unavailable

13

NO DESCRIPTION AVAILABLE | FOR 7JK; Includes Item(s) 14 - 15 This part replaces 94430-27A50-019.

94430-27A30

Unavailable

14

NO DESCRIPTION AVAILABLE This part replaces 68111-31300-66P.

68111-00A10-66P

Unavailable

15

TAPE SET, RH | FOR 14L

68680-27A21-81F

Unavailable

15

TAPE SET, RH | FOR 019

68680-27A21-65G

Unavailable

16

NO DESCRIPTION AVAILABLE | FOR 7GF This part replaces 94440-27A50-14L.

94440-27A30

Unavailable

16

NO DESCRIPTION AVAILABLE | FOR 7JK; Includes Item(s) 17 - 18 This part replaces 94440-27A50-019.

94440-27A30

Unavailable

17

NO DESCRIPTION AVAILABLE This part replaces 68111-31300-66P.

68111-00A10-66P

Unavailable

18

TAPE SET, LH | FOR 14L

68690-27A21-81F

Unavailable

18

TAPE SET, LH | FOR 019

68690-27A21-65G

Unavailable

19

SCREW, REAR

09139-06027

$2.16

20

WASHER

09169-06033

$1.50

21

SCREW

09139-06030

$3.70

22

CUSHION

94570-04A00

$21.91

23

BRACE, FRONT This part replaces 94510-27A40.

94510-27A60

Unavailable

24

BOLT, EXHAUST COVER This part replaces 07120-06165.

07120-0616B

$2.45

25

BOLT This part replaces 07120-08165.

07120-0816A

$3.05

26

BRACE, REAR

94530-27A10

Unavailable

27

NO DESCRIPTION AVAILABLE | FOR 7GF This part replaces 94470-27A40-7TG.

94470-27A41-13L

Unavailable

27

NO DESCRIPTION AVAILABLE | FOR 7JK; Includes Item(s) 28 - 28 This part replaces 94470-27A40-7JK.

94470-27A41-13L

Unavailable

28

EMBLEM | FOR 7TG This part replaces 68261-27A00-73H.

68261-27A00-8KE

Unavailable

28

EMBLEM | FOR 7JK

68261-27A00-60D

Unavailable

29

NO DESCRIPTION AVAILABLE | FOR 7GF This part replaces 94480-27A40-7TG.

94480-27A40-13L

Unavailable

29

NO DESCRIPTION AVAILABLE | FOR 7JK; Includes Item(s) 30 - 30 This part replaces 94480-27A40-7JK.

94480-27A40-13L

Unavailable

30

EMBLEM | FOR 7TG This part replaces 68261-27A10-73H.

68261-27A00-8KE

Unavailable

30

EMBLEM | FOR 7JK This part replaces 68261-27A10-60D.

68261-27A00-60D

Unavailable

31

SCREW, UPPER

09139-06030

$3.70

32

SCREW, RH & LH

09139-06039

$2.19

33

BRACE, LOWER

94490-06B00

Unavailable

34

SCREW

09139-06028

$3.70

35

CUSHION

09320-09016

$1.97

36

SPACER This part replaces 09180-06152.

09180-06262

$2.55

37

WASHER (6.5X18X1)

09160-06056

$1.72

38

WASHER

09160-06094

$1.49

39

NO DESCRIPTION AVAILABLE | FOR 7GF This part replaces 94475-06B00-14L.

94475-06B01-13L

Unavailable

39

NO DESCRIPTION AVAILABLE | FOR 7JK This part replaces 94475-06B00-019.

94475-06B01-13L

Unavailable

40

SCREW

09139-05025

$2.05

41

NUT This part replaces 08316-26055.

08316-2005A

$2.19

42

BRACE, LOWER RH

94580-27A00

Unavailable

43

BRACE, LOWER LH

94590-27A00

Unavailable

44

BRACE, LOWER REAR

94493-06B00

Unavailable

45

BOLT This part replaces 01517-06128.

01550-06127

$2.30

46

LOCK WASHER This part replaces 08321-31064.

08321-0106A

$1.84

47

SCREW

09139-06030

$3.70
