Description

Price

1

PUMP ASSY,WATER | Includes Item(s) 2 - 11 This part replaces 17400-01H00-E00.

17400-01H01

$265.51

2

IMPELLER

17491-17E01

$26.34

3

GASKET

09168-06025

$2.80

4

.SEAL,MECHANICAL This part replaces 17470-02F10.

17470-02F11

$27.96

5

OIL SEAL

17461-01H00

$16.83

6

WASHER

09181-10167

$2.06

7

SCREW This part replaces 02112-06163.

02112-0616A

$1.46

8

.O-RING This part replaces 17418-33400.

17418-33401

$4.28

9

.O-RING

17435-33400

$14.63

10

BOLT (6X13)

09100-06099

$2.08

11

LOCK WASHER

09164-06006

$2.66

12

BOLT

01547-0635A

$2.38

Suzuki GSX-R750 (2007) WATER PUMP Diagram
