Description

Price

1

PAN, OIL | MODEL Y/K1 This part replaces 11511-35F00.

11511-35F01

$215.64

1

PAN, OIL | MODEL K2/K3

11511-35F01

$215.64

2

GASKET, OIL PAN

11489-35F00

$14.46

3

BOLT, TENSIONER ADJUSTER This part replaces 09103-06221.

09103-06250

$2.23

4

GASKET (5.8X13X1.2)

09168-06023

$2.35

5

PLUG, OIL DRAIN

09247-14036

$6.17

6

GASKET

09168-14002

$2.26

7

STRAINER ASSY,E This part replaces 16520-35F00.

16520-35F01

$22.37

8

BOLT This part replaces 01550-06203.

01550-0620A

$1.97

9

O RING (D:2.62,ID:20.3)

09280-19008

$5.50

10

VALVE ASSY, OIL RELIEF

16440-24F00

$50.04

11

PUMP ASSY,ENG OIL

16400-35F00

$194.98

12

O RING

16491-35F00

$6.22

13

..BOLT This part replaces 01547-06203.

01547-0620B

$2.45

14

GEAR, OIL PUMP DRIVE | MODEL Y/K1/K2 This part replaces 16321-35F00.

16321-35F01

$69.38

14

GEAR, OIL PUMP DRIVE | MODEL K3

16321-35F01

$69.38

15

GEAR, OIL PUMP DRIVEN

16331-35F00

$74.08

16

WASHER

09181-10158
