2003 Suzuki GSX-R600 Headlamp Diagram

← All diagrams

Find the part on the Headlamp diagram for your 2003 Suzuki GSX-R600, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2003 Suzuki GSX-R600 Headlamp Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

HEADLAMP ASSY | Includes Item(s) 2 - 3

35100-35F30-999

1
Out of stock

2

COVER, SOCKET

35125-77A00

2

$18.23

In stock

3

ADAPTER ASSY

34175-33E50

2

$18.44

In stock

4

2

$22.21

In stock

5

.CUSHION (9X18X14) This part replaces 09320-09039.

09320-09059

4
Out of stock

6

WASHER (5.5X18X1)

09160-05045

4

$2.10

In stock

7

4

$0.78

In stock

8

2

$17.36

In stock

9

BRACKET, FRONT SIDE REAR

35956-35F00

2
Out of stock

10

NUT This part replaces 08310-00053.

08310-0005A

2
Out of stock
