Suzuki GSX-R250L3 (2013) WIRING HARNESS Diagram

#

Description
Price

1

HARNESS, WIRING

36610-48H60-000

Unavailable

2

.FUSE (10A)

09481-10501-000

Unavailable

3

.FUSE (15A)

09481-15501-000

Unavailable

4

CLAMP, WIRING HARNESS

36990-32G10-000

Unavailable

5

CLAMP, WIRING HARNESS

36990-32G20-000

Unavailable

6

CLAMP (L:248)

09407-25402-000

Unavailable

7

CLAMP (L:235)

09407-25401-000

Unavailable

8

CLAMP, WIRING HARNESS

36990-48H00-000

Unavailable

9

CLAMP, WIRING HARNESS

36990-45H30-000

Unavailable

10

CLAMP (L:190)

09407-19401-000

Unavailable

11

CLAMP, WIRING HARNESS

36990-32G30-000

Unavailable

12

CLAMP, WIRING HARNESS

36990-48H10-000

Unavailable

13

SWITCH ASSY, STOP LAMP

37740-33G00-000

Unavailable

14

SPRING

09443-06046-000

Unavailable

15

SWITCH ASSY, SIDE STAND

37840-18J00-000

Unavailable

16

BOLT

01550-0620B-000

Unavailable

17

RELAY ASSY, SIDE STAND

38740-33G00-000

Unavailable

18

HORN ASSY

38500-48H01-000

Unavailable

19

PLATE, HORN

38590-48H00-000

Unavailable

20

BOLT

01550-0812B-000

Unavailable

21

.BOLT

01550-0612B-000

Unavailable

22

RELAY ASSY, FUEL PUMP

38740-33G00-000

Unavailable

23

RELAY ASSY, FAN MOTOR

38740-33G00-000

Unavailable

24

WIRE, OIL PRESSURE SWITCH LEAD

36851-48H01-000

Unavailable

25

PROTECTOR, WIRING HARNESS

36618-48H00-000

Unavailable
