Suzuki GSX-R250L3 (2013) REAR COMBINATION LAMP Diagram

#

Description

Price

1

LAMP ASSY, REAR COMBINATION

35710-48H01-000

Unavailable

2

BULB (12V,21/5W)

09471-12083-000

Unavailable

3

LENS

35732-48H00-000

Unavailable

4

LENS

35712-48H01-000

Unavailable

5

GASKET

35713-48H00-000

Unavailable

6

SCREW

03211-0435A-000

Unavailable

7

SCREW

03241-0514A-000

Unavailable

8

WASHER

08212-05181-000

Unavailable

9

CUSHION

35765-48H00-000

Unavailable

10

BRACKET

35726-48H00-000

Unavailable

11

NUT, REAR LAMP

35157-48H00-000

Unavailable

12

CLAMP, REAR COMBINATION LAMP

36990-48H20-000

Unavailable

13

SCREW

03541-0516A-000

Unavailable

14

LAMP ASSY, LICENSE

35910-48H01-000

Unavailable

15

.BULB (12V5W)

09471-12216-000

Unavailable

16

SPACER, LICENSE LAMP

35996-48H30-000

Unavailable

17

WASHER (6.5X20X1.2)

09160-06077-000

Unavailable

18

CUSHION

35929-48H00-000

Unavailable

19

NUT (6X12)

08316-1006A-000

Unavailable

20

BRACKET, LICENSE PLATE

35927-48H30-000

Unavailable

21

WASHER (6.5X16X1.2)

09160-06019-000

Unavailable

22

.SCREW

02142-0616A-000

Unavailable

23

NUT (6X12)

08316-1006A-000

Unavailable

24

REFLECTOR ASSY, REAR SIDE

35950-04HA0-000

Unavailable

25

NUT

08316-1005A-000

Unavailable
