Suzuki GSX-R250L3 (2013) RADIATOR HOSE Diagram

#

Description
Price

1

CONNECTOR, THERMOSTAT INLET

17662-48H00-000

Unavailable

2

THERMOSTAT, WATER

17670-48H00-000

Unavailable

3

BOLT

01550-0616A-000

Unavailable

4

HOSE, RADIATOR OUTLET

17851-48H00-000

Unavailable

5

HOSE, WATER PUMP INLET

17852-48H00-000

Unavailable

6

HOSE, WATER PUMP OUTLET

17853-48H00-000

Unavailable

7

HOSE, CYLINDER CONNECTOR

17854-48H00-000

Unavailable

8

HOSE, THERMOSTAT CONNECTOR

17855-48H00-000

Unavailable

9

HOSE, RADIATOR INLET

17856-48H00-000

Unavailable

10

HOSE, WATER BYPASS

17857-48H00-000

Unavailable

11

CONNECTOR, CYL WATER INLET

17861-48H00-000

Unavailable

12

O RING, CYL INLET CONNECTOR

17863-48H00-000

Unavailable

13

PIPE, WATER PUMP

17870-48H00-000

Unavailable

14

PIPE, CYLINDER HEAD OUTLET

17880-48H00-000

Unavailable

15

WASHER (6.5X18X1)

09160-06028-000

Unavailable

16

SPACER (6.5X9X5)

09180-06365-000

Unavailable

17

O RING (D:3.2,ID:17.8)

09280-18011-000

Unavailable

18

CUSHION

09320-08084-000

Unavailable

19

CLIP

09401-12L02-000

Unavailable

20

CLAMP

09402-27L01-000

Unavailable

21

CLAMP

09402-32L01-000

Unavailable

22

BOLT

01547-0620A-000

Unavailable

23

BOLT (6X20)

01550-0620A-000

Unavailable

24

BOLT

07130-0612A-000

Unavailable

25

TANK ASSY, RESERVOIR

17910-48H00-000

Unavailable

26

CAP, RESERVOIR TANK

17932-12C00-000

Unavailable

27

BRACKET, RESERVOIR TANK

17920-48H00-000

Unavailable

28

HOSE, RESERVOIR TANK INLET | CUT AS REQUIRED

17981-19F00-000

Unavailable

29

HOSE, RESERVOIR TANK OVER FLOW

17900-44810-000

Unavailable

30

HOSE, FUEL TANK WATER DRAIN

17985-48H00-000

Unavailable

31

BOLT (6X12)

09111-06083-000

Unavailable

32

3 WAY

09367-08005-000

Unavailable

33

CLIP

09401-08L01-000

Unavailable

34

CLAMP, RSVR TANK OVFL HOSE

29404-93J10-000

Unavailable

35

FUEL TANK WATER DRAIN HOSE

29404-93J10-000

Unavailable

36

BOLT

07120-0612A-000

Unavailable

37

CAP, RADIATOR 1.1

17730-48H00-000

Unavailable

38

CONDUCTION, RADIATOR

17791-48H00-000

Unavailable

39

BOLT (6X20)

01550-0620A-000

Unavailable

40

SENSOR,TEMP

13650-49X00-000

Unavailable

41

GASKET, TEMP SENSOR

13651-48H00-000

Unavailable
