Suzuki GSX-R250L3 (2013) FRAME COVER Diagram

#

Description
Price

1

COVER, FRAME RH (BLACK)

47111-48H00-YKV

$83.52

2

COVER, FRAME FRONT RH (SILVER/BLACK)

47121-48H00-AB4

$69.42

3

CUSHION, COVER FRONT

47161-48H00-000

Unavailable

4

CUSHION, COVER UPPER

47161-48H00-000

Unavailable

5

COVER, FRAME LH (BLACK)

47211-48H00-YKV

Unavailable

6

COVER, FRAME FRONT LH (SILVER/BLACK)

47221-48H00-AB4

$69.42

7

COVER, FRAME UPPER CENTER (BLACK)

47311-48H00-YAY

Unavailable

7

COVER, FRAME UPPER CENTER (RED)

47311-48H00-PDD

Unavailable

8

COVER, FRAME HEAD RH

47351-48H00-000

Unavailable

9

COVER, FRAME HEAD LH

47361-48H00-000

Unavailable

10

NUT

47399-48H00-000

Unavailable

11

COVER, FRAME UPPER RH (BLACK)

47831-48H00-YAY

$235.14

11

COVER, FRAME UPPER RH (RED)

47831-48H00-PDD

$227.33

12

COVER,FRAME UPR This part replaces 47841-48H00-YAY.

47841-48H01-YAY

$167.20

12

COVER, FRAME UPPER LH (RED)

47841-48H00-PDD

$221.77

13

CUSHION, COVER UPPER REAR

47845-48H00-000

Unavailable

14

CUSHION, COVER UPPER

47846-48H00-000

Unavailable

15

CUSHION, COVER FRONT

47846-48H00-000

Unavailable

16

CUSHION, FRAME COVER

47846-48H00-000

Unavailable

17

CLIP, COVER UPPER

48292-32GH0-000

Unavailable

18

NUT, COVER FRAME FRONT

93162-37G00-000

Unavailable

19

SCREW, FRAME HEAD COVER

47353-48H00-000

Unavailable

20

WASHER (6.5X20X1.2)

09160-06077-000

Unavailable

21

WASHER (6.5X20X1.2)

09160-06077-000

Unavailable

22

SPACER (6.5X10X7)

09180-06283-000

Unavailable

23

SPACER (6.5X10X7)

09180-06283-000

Unavailable

24

CUSHION (8X26X7)

09320-08018-000

Unavailable

25

CUSHION (8X26X7)

09320-08018-000

Unavailable

26

.SCREW

02142-0616A-000

Unavailable

27

SCREW

02142-0620A-000

Unavailable

28

SCREW

03541-0516A-000

Unavailable

29

SCREW

03541-0516A-000

Unavailable

30

SCREW

03541-0516A-000

Unavailable

31

EMBLEM, FRAME COVER RH (SILVER/GRAY)

68131-48H50-AFT

$6.88

32

EMBLEM, FRAME COVER LH (SILVER/GRAY)

68141-48H50-AFT

$6.88
