Suzuki GSX-R250L3 (2013) CAM SHAFT/VALVE Diagram

#

Description

Price

1

CAMSHAFT

12710-48H00-000

Unavailable

2

ARM, VALVE ROCKER

12840-20H10-000

Unavailable

3

SCREW, TAPPET ADJUSTING

12842-49220-000

Unavailable

4

NUT, TAPPET ADJUSTING

12843-27A10-000

Unavailable

5

SHAFT, VALVE ROCKER ARM

12861-48H00-000

Unavailable

6

WASHER (12.7X18.1X0.2)

09164-12018-000

Unavailable

7

VALVE, INTAKE

12911-20H10-000

Unavailable

8

VALVE, EXHAUST

12912-20H10-000

Unavailable

9

SPRING SET, VALVE

12920-48H00-000

Unavailable

10

RETAINER, VALVE SPRING

12931-27A30-000

Unavailable

11

COTTER, VALVE

12932-27A10-000

Unavailable

12

SEAT, VALVE SPRING

12933-81410-000

Unavailable

13

OIL SEAL (5X10X8)

09289-05016-000

Unavailable

14

SPROCKET, CAMSHAFT (NT:38)

12741-48H00-000

Unavailable

15

BOLT (6X12.5)

09111-06027-000

Unavailable

16

C RING

09390-22002-000

Unavailable
