Suzuki GSX-R250L3 (2013) AIR CLEANER Diagram

#

Description

Price

1

CLEANER ASSY, AIR

13700-48H01-000

Unavailable

2

GASKET

13746-48H00-000

Unavailable

3

CAP, AIR CLEANER

13740-48H00-000

Unavailable

4

GASKET

13746-48H00-000

Unavailable

5

TUBE, INLET

13891-48H00-000

Unavailable

6

FILTER ASSY

13780-48H00-000

Unavailable

7

CLAMP

13826-48H00-000

Unavailable

8

SCREW

02142-0512A-000

Unavailable

9

TUBE, BREATHER

13853-48H00-000

Unavailable

10

CLIP (ID:15.5)

09401-15101-000

Unavailable

11

PLUG, DRAIN

13878-48H00-000

Unavailable

12

.CLIP (ID:14.5)

09401-14101-000

Unavailable

13

BOLT

01550-0610A-000

Unavailable

14

BOLT

01500-0620A-000

Unavailable

15

WASHER

08321-0106A-000

Unavailable

16

WASHER (6.5X20X1.2)

09160-06077-000

Unavailable

17

SENSOR, BOOST

15630-29G20-000

Unavailable

18

COVER

15625-29G10-000

Unavailable

19

SENSOR,INLET AIR TEMP

13650-52G00-000

Unavailable

20

GROMMET, AIR TEMP SENSOR

13655-77E00-000

Unavailable
