Suzuki GSX-R1000AL8 (2018) GEAR SHIFTING (GSX-R1000RZL8 E33) Diagram

#

Description
Price

1

FORK,GEAR SHIFT NO.1

25211-01H11

$80.17

2

FORK,GEAR SHIFT NO.3

25231-01H02

$78.68

3

SHAFT, GEAR SHIFT FORK

25411-38B01

$28.93

4

SCREW (6X12)

09136-06147

$3.20

5

CAM,GEAR SHIFT

25310-17K00

$195.67

6

BOLT,GEAR SHIFT CAM PLATE

25312-17K00

$23.08

7

PLATE,GEAR SHIFT CAM

25381-17K00

$43.73

8

SCREW (6X12)

09136-06147

$3.20

9

BEARING (25X47X8)

09262-25006

$25.54

10

BEARING (25X32X12)

09263-25018

$21.39

11

STOPPER,SHIFT CAM This part replaces 25350-06G00.

25350-06G10

$18.03

12

SPRING,GEAR SHIFT CAM STOPPER

25355-17K00

$3.93

13

BOLT (6X14.3)

09111-06041

$2.61

14

WASHER

08211-06141

$1.59

15

SHAFT,GEAR SHIFT

25510-17K00

$86.88

16

PLATE,GEAR SHIFT CAM DRIVE

25512-06G20

$24.37

17

SPRING, GEAR SHIFT PLATE

25518-01H00

$3.70

18

WASHER, GEAR SHIFT SHAFT END

25519-01H00

$5.98

19

STOPPER, GEAR SHIFT ARM

25671-01011

$4.48

20

SCREW (6X16)

09126-06014

$2.06

21

WASHER (14X29X0.8)

09160-14016

$1.93

22

SHIM (14X24X1)

09181-14195

$2.71

23

BEARING (14X20X12)

09263-14027

$13.52

24

OIL SEAL (14X22X6)

09283-14006

$6.70

25

SPRING

09444-20001

$5.24

26

CIRCLIP

08331-3114A

$1.91

27

ARM,GEAR SHIFT LINK This part replaces 25520-17K00.

25520-17K10

$67.22

28

ROD,GEAR SHIFT LINK

25525-17K10

$29.08

29

LEVER ASSY,GEAR SHIFT

25600-17K00

$120.25

30

.RUBBER, GEAR SHIFT PEDAL

25652-20C00

$5.44

31

.SEAL (18X24X3.5)

09284-18005

$6.47

32

BOLT (8X20)

09106-08167

$3.35

33

NUT

09140-06025

$2.05

34

WASHER (10X30X2.5)

09160-10144

$5.28

35

BOLT

07120-0625A

$2.50

36

NUT

09140-06020

$2.02

37

SHAFT,GEAR SHIFT LEVER

25617-17K00

$22.20

38

BRACKET,GEAR SHIFT LEVER

25681-17K00

$66.78

39

WASHER,GEAR SHIFT LEVER LH

25619-17K00

$4.55

40

SENSOR ASSY,GEAR POSITION

37730-17K00

$152.90

41

BOLT (5X16)

09106-05023

$2.92

42

O RING (D:2.4,ID:26.2)

09280-26005

$2.30

43

CLAMP (L:45)

09404-06429

$1.83

44

SENSOR & ROD SE This part replaces 25501-17810.

25501-17811

$535.87

45

CLAMP (L:145)

09407-14407

$3.57
