Description

Price

1

TANK ASSY,FUEL (BLACK)

44100-17K00-YKV

$1,001.35

2

VESSEL,FUEL TANK INNER This part replaces 44121-17K00.

44121-17K01

$16.35

3

CAP SET,FUEL TANK FILLER

44200-17820

$218.08

4

BOLT, FUEL TANK FILLER CAP

44244-11J00

$4.00

5

MOLDING, FUEL TANK REAR

44552-24B10

$11.18

6

NUT

44523-47H00

$10.02

7

BRACKET,FUEL TANK NO.1

44530-17K00

$28.83

8

CUSHION,FUEL TANK SIDE

44541-17K00

$5.13

9

CUSHION,FUEL TANK REAR

44542-17K00

$11.33

10

SPACER,FUEL TANK REAR BRKT

44544-17K00

$7.75

11

BRACKET,FUEL TANK REAR

44551-17K00

$62.72

12

CLIP,NUT

44552-17K00

$5.22

13

SPACER, JOINT

44561-18G00

$16.96

14

BOLT (6X125)

09103-06033

$3.91

15

BOLT (6X18)

09111-06081

$4.09

16

SCREW (6X22)

09139-06191

$4.03

17

NUT (M6)

09159-06086

$2.04

18

WASHER This part replaces 09160-06012.

09160-06054

$1.62

19

CUSHION

09320-08071

$3.25

20

CUSHION,FUEL TANK COVER

44543-17K00

$3.50

21

FASTENER, COVER SIDE

44572-13G00

$11.07

22

FASTENER, COVER FRONT

44572-44G00

$10.18

23

NUT

09148-05052

$3.37

24

CLAMP(L:80) This part replaces 09404-06433.

09404-06036

$1.74

25

CLAMP (L:154)

09407-17403

$4.91

26

PROTECTOR,FUEL TANK

44283-17K00

$13.08

27

HOSE, DRAIN

44423-17K01

Unavailable

28

STAY,FUEL TANK | OPT

44574-17K00

$35.02

29

PROTECTOR,FUEL TANK NO.2,R

44285-17K00

$9.83

30

PROTECTOR,FUEL TANK NO.2,L

44286-17K00
