Description

Price

1-1

TANK ASSY,FUEL (BLACK) | FOR YKV

44100-17K00-YKV

$1,093.28

1-2

TANK ASSY, FUEL (RED) | FOR YVZ

44100-17K00-YVZ

Unavailable

2

VESSEL,FUEL TANK INNER This part replaces 44121-17K00.

44121-17K01

$18.47

3

CAP SET,FUEL TANK FILLER

44200-17820

$242.68

4

BOLT, FUEL TANK FILLER CAP

44244-11J00

$3.93

5

MOLDING, FUEL TANK REAR

44552-24B10

$12.62

6

NUT

44523-47H00

$13.30

7

BRACKET,FUEL TANK NO.1

44530-17K00

$32.53

8

CUSHION,FUEL TANK SIDE

44541-17K00

$5.80

9

CUSHION,FUEL TANK REAR

44542-17K00

$9.48

10

SPACER,FUEL TANK REAR BRKT

44544-17K00

$8.75

11

BRACKET,FUEL TANK REAR

44551-17K00

$70.78

12

CLIP,NUT

44552-17K00

$5.90

13

SPACER, JOINT

44561-18G00

$16.22

14

BOLT (6X125)

09103-06033

$3.66

15

BOLT (6X18)

09111-06081

$3.98

16

SCREW (6X22)

09139-06191

$3.79

17

NUT (M6)

09159-06086

$2.12

18

WASHER This part replaces 09160-06012.

09160-06054

$1.66

19

CUSHION

09320-08071

$3.16

20

CUSHION,FUEL TANK COVER

44543-17K00

$4.63

21

FASTENER, COVER SIDE

44572-13G00

$10.59

22

FASTENER, COVER FRONT

44572-44G00

$9.75

23

NUT

09148-05052

$3.13

24

CLAMP(L:80) This part replaces 09404-06433.

09404-06036

$1.81

25

CLAMP (L:154)

09407-17403

$4.79

26

PROTECTOR,FUEL TANK

44283-17K00

$14.77

27

HOSE,FUEL TANK WATER DRAIN This part replaces 44423-17K00.

44423-17K02

$19.52

28

STAY,FUEL TANK | OPT

44574-17K00

$39.52

Suzuki GSX-R1000AL (2017) FUEL TANK (GSX-R1000AL7 E33) (YKV,YVZ) Diagram
