Suzuki GSX-R1000 (2006) UNDER COWLING (MODEL K6) Diagram

#

Description
Price

1

COWL, UNDER RH (WHITE) | FOR LR5

94470-41G30-YBD

$1,056.17

1

COWL, UNDER RH (BLACK) | FOR BZG

94470-41G30-019

$1,036.62

1

COWL, UNDER RH (BLACK) | FOR CRS

94470-41G30-1PX

Unavailable

1

COWL, UNDER RH (GRAY) | FOR CRT

94470-41G30-YHF

$1,056.17

1A

COWL, UNDER RH (BLACK) | FOR CRU

94470-41G40-YKV

Unavailable

2

COWL,UNDER,L(WH | FOR LR5 This part replaces 94480-41G30-YBD.

94480-41G31-YBD

Unavailable

2

COWL,UNDER,L(BL | FOR BZG This part replaces 94480-41G30-019.

94480-41G31-019

Unavailable

2

COWL, UNDER LH (BLACK) | FOR CRS

94480-41G30-1PX

Unavailable

2

COWL,UNDER,L(GR | FOR CRT This part replaces 94480-41G30-YHF.

94480-41G31-YHF

Unavailable

2A

COWL, UNDER LH (BLACK) | FOR CRU; Includes Item(s) 3 - 8

94480-41G40-YKV

Unavailable

3

TAPE, UPPER RH | FOR YBD

68185-41G00-CNR

Unavailable

3

TAPE, UPPER RH | FOR 019,1PX

68185-41G00-2UR

Unavailable

3

TAPE, UPPER RH | FOR YHF

68185-41G00-CVN

Unavailable

3A

TAPE, UPPER RH | FOR YKV

68185-41G10-CVR

Unavailable

4

TAPE, UPPER LH | FOR YBD

68195-41G00-CNR

Unavailable

4

TAPE, UPPER LH | FOR 019,1PX

68195-41G00-2UR

Unavailable

4

TAPE, UPPER LH | FOR YHF

68195-41G00-CVN

Unavailable

4A

TAPE, UPPER LH | FOR YKV

68195-41G10-CVR

Unavailable

5

TAPE, CENTER RH | FOR YBD

68185-41G20-CVJ

Unavailable

5

TAPE, CENTER RH | FOR 019

68185-41G20-CVK

Unavailable

5

TAPE, CENTER RH | FOR 1PX

68185-41G20-CVL

Unavailable

5

TAPE, CENTER RH | FOR YHF

68185-41G20-CVM

Unavailable

5

TAPE, CENTER RH | FOR YKV

68185-41G20-CVP

Unavailable

6

TAPE, COVER LH | FOR YBD

68195-41G20-CVJ

Unavailable

6

TAPE, COVER LH | FOR 019

68195-41G20-CVK

Unavailable

6

TAPE, COVER LH | FOR 1PX

68195-41G20-CVL

Unavailable

6

TAPE, COVER LH | FOR YHF

68195-41G20-CVM

Unavailable

6

TAPE, COVER LH | FOR YKV

68195-41G20-CVP

Unavailable

7

EMBLEM, RH (BLACK) | FOR YBD,YKV

68181-41G00-019

$43.27

7

EMBLEM, RH (SILVER) | FOR 019

68181-41G00-YD8

Unavailable

7

EMBLEM, RH (GRAY) | FOR 1PX,YHF

68181-41G00-YU8

$40.82

8

EMBLEM, LH (BLACK) | FOR YBD,YKV

68191-41G00-019

$43.27

8

EMBLEM, RH (SILVER) | FOR 019

68191-41G00-YD8

Unavailable

8

EMBLEM, RH (GRAY) | FOR 1PX,YHF

68191-41G00-YU8

Unavailable

9

SCDREW, UPPER

09139-06126

$4.04

10

CUSHION

09320-09016

$1.97

11

SCREW, REAR

09139-05064

$2.57

12

CUSHION, CENTER

09320-08028

$3.04

13

SHIELD FRONT RH

94472-41G00

$22.92

14

SHIELD, REAR RH

94472-41G10

$15.23

15

SHIELD, LH

94482-41G00

$44.93

16

BRACKET, RH

94530-41G00

Unavailable

17

BRACKET, LOWER RH This part replaces 94540-41G00.

94540-41G01

$12.40

18

BOLT, CLAMP This part replaces 01550-06123.

01550-0612A

$1.97

19

CLIP

94479-35F00

$5.62

20

SCREW This part replaces 03541-05163.

03541-0516A

$1.49

21

COVER,UNDER COW This part replaces 94475-41G00.

94475-41G01

$75.83

22

COVER,UNDER COW This part replaces 94485-41G00.

94485-41G01

$85.60

23

CUSHION, LH

09321-10018

$5.45

24

CUSHION, RH

09321-10040

$14.53

25

SCREW This part replaces 03541-05163.

03541-0516A

$1.49

26

CUSHION, RH

94476-41G00

$10.48
