Suzuki GSX-R1000 (2004) TURN SIGNAL LAMP Diagram

#

Description
Price

1

LAMP ASSY, FRONT TURN RH

35601-18G00

Unavailable

1

LAMP ASSY, FRONT TURN LH | Includes Item(s) 2 - 4

35602-18G00

Unavailable

2

LENS, RH This part replaces 35612-18G00.

35612-18G01

Unavailable

2

LENS, LH This part replaces 35632-18G00.

35632-18G01

Unavailable

3

BULB (12V,18W)

35222-18G00

Unavailable

4

SCREW

35725-40511

$1.91

5

PLATE, FR TURNSIGNAL

35629-18G00

$2.42

6

NUT This part replaces 08316-10053.

08316-1005A

$2.19

7

LAMP ASSY, REAR TURN RH

35603-18G30

Unavailable

7

LAMP ASSY, REAR TURN LH | Includes Item(s) 8 - 10

35604-18G30

$98.00

8

LENS, LH This part replaces 35632-18G00.

35632-18G01

Unavailable

8

LENS, RH This part replaces 35612-18G00.

35612-18G01

Unavailable

9

BULB (12V,18W)

35222-18G00

Unavailable

10

SCREW

35725-40511

$1.91

11

PLATE, REAR TURN RH

35669-18G00

Unavailable

11

PLATE, REAR TURN LH

35679-18G00

Unavailable

12

NUT This part replaces 08316-10053.

08316-1005A

$2.19

13

REFLECTOR ASSY, RR SIDE

35970-14A20

$15.10

14

NUT This part replaces 08316-10053.

08316-1005A

$2.19

15

RELAY ASSY,TURN This part replaces 38610-07F00.

38610-07F01

Unavailable
