Suzuki GSX-R1000 (2004) FUEL TANK (GSX-R1000K4 E3,E28,E33) Diagram

#

Description
Price

1

TANK ASSY,FUEL( | E3,E28 FOR LR5 This part replaces 44100-18G60-YBA.

44110-18G00-13L

Unavailable

1

TANK ASSY, FUEL (YELLOW) | E3,E28 FOR LR7

44100-18G60-YU9

Unavailable

1

TANK ASSY,FUEL( | E3,E28 FOR AGR This part replaces 44100-18G60-019.

44110-18G00-13L

Unavailable

1

TANK ASSY, FUEL (BLUE) | E33 FOR LR5

44100-18G80-YBA

Unavailable

1

TANK ASSY, FUEL (YELLOW) | E33 FOR LR7

44100-18G80-YU9

Unavailable

1

TANK ASSY, FUEL (BLACK) | E33 FOR AGR; Includes Item(s) 2 - 4

44100-18G80-019

Unavailable

2

TAPE SET, UPPER | FOR YBA

68110-18G20-LS3

Unavailable

2

TAPE SET, UPPER | FOR YU9

68110-18G20-LB4

Unavailable

2

TAPE SET, UPPER | FOR 019

68110-18G20-CT5

Unavailable

3

TAPE SET, LOWER (WHITE) | FOR YBA

68110-18G30-YBD

Unavailable

3

TAPE SET, LOWER (BLACK) | FOR YU9

68110-18G30-019

Unavailable

3

TAPE SET, LOWER (SILVER) | FOR 019

68110-18G30-YD8

Unavailable

4

EMBLEM,FUEL TAN | FOR YBA This part replaces 68111-18G00-ABF.

68111-18G01-0AT

$14.26

4

EMBLEM,FUEL TAN | FOR YU9 This part replaces 68111-18G00-ASJ.

68111-18G01-YGP

Unavailable

4

EMBLEM,FUEL TAN | FOR 019 This part replaces 68111-18G00-E9Y.

68111-18G01-0AT

$14.26

5

CAP SET,FUEL TA | E3,E28 This part replaces 44200-16850.

44200-16852

$118.21

5

CAP SET,FUEL TA | E33 This part replaces 44200-16860.

44200-16862

$242.83

6

BOLT

09106-05017

$2.83

7

BOLT, FRONT

09139-06029

$5.36

8

WASHER

09160-06054

$1.62

9

CUSHION,FUEL TA This part replaces 44511-19F00.

44511-19F01

$5.68

10

SPACER, FRONT

44512-19F00

$7.44

11

CUSHION,FUEL TA This part replaces 44542-18G00.

44542-18G01

$7.98

12

BRACKET, REAR NO.1

44530-18G00

Unavailable

13

SCREW (6X22) This part replaces 09139-06132.

09139-06191

$4.03

14

CUSHION

09320-08071

$3.25

15

BOLT, JOINT

09106-06103

$4.40

16

SPACER

44561-18G00

$16.96

17

STAY, FUEL TANK

44574-35F00

$15.16

18

HOSE,WATER DRAI This part replaces 44423-16G01.

44423-16G02

$13.41

19

CLAMP This part replaces 09404-06431.

09404-06039

$1.74

20

HOSE,FUEL TANK | E33 This part replaces 44424-16G00.

44424-18G01

$10.62

20

HOSE,FUEL TANK | E3,E28 This part replaces 44424-18G00.

44424-18G01

$10.62
