Ski-Doo GSX LTD 600 HO SDI, 2008 02- Throttle Body Diagram

#

Description
Price

1

THROTTLE BODY - Call your local BRP dealership

420892132

Unavailable

2

Position Sensor

420866120

$98.99

3

Flat Washer 4 mm, Stainless

234041600

$1.15

4

Phillips Screw M4 X 16

208641660

$0.90

5

HOSE - Call your local BRP dealership

420460860

Unavailable

6

Norma Spring Clamp

293650214

$15.89

7

High Pressure Air Hose, 380 mm

420660577

Unavailable

8

Solenoid Valve

270600005

$116.49

9

High Pressure Air Hose, 180 mm

420660571

$14.22

10

T-Fitting

293710068

$8.29

11

HIGH PRESSURE AIR HOSE, 50 MM - Call your local BRP dealership

420660572

Unavailable

12

HIGH PRESSURE AIR HOSE, 80 MM - Call your local BRP dealership

420460852

Unavailable

13

Gear Clamp

420853658

$7.65

14

Y-Fitting

293710059

$9.69

15

HIGH PRESSURE AIR HOSE, 40 MM - Call your local BRP dealership

420460851

$13.49

16

Check Valve

420660543

$29.99

17

MOLDED HOSE - Call your local BRP dealership

420460782

Unavailable

18

MOLDED HOSE - Call your local BRP dealership

420460786

Unavailable

19

Norma Spring Clamp

293650214

$15.89

20

Tie Wrap 94 mm | 4X4

293750001

$1.03
