Sea-doo GSX Limited, 5629/5845, 1998 Oil Injection System Diagram

#

Description
Price

1

Oil Tank

275000238

$98.99

2

Elbow Fitting 90°

293710070

Unavailable

3

Grommet

293720008

$14.75

4

Oil Cap | Includes 4 - 5.

275000220

Unavailable

5

Snap Cap

293000074

Unavailable

6

Tie Wrap 94 mm | 4X4

293750001

$1.03

7

Filler Neck

275000187

Unavailable

8

Restrictor

275000190

Unavailable

9

Était/Was 293800038 Loctite 518, 50 ml

219704456

$53.99

10

Gasket

293250029

$14.82

11

Filler Neck Nut, Fuel

211100012

$14.22

12

Filler Hose

275000188

Unavailable

13

Tridon Clamp

293650035

$7.29

14

GASKET - Call your local BRP dealership This part replaces 293250075.

293250211

Unavailable

15

Oetiker Clamp

293650042

$3.09

16

HOSE-6MM. 5000MM LONG - Call your local BRP dealership

219704396

Unavailable

17

Tie Wrap 142 mm

293750002

$1.25

18

Check Valve

275500398

$10.99

19

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

$32.99

20

OIL FILTER - Call your local BRP dealership

275000051

Unavailable

21

Oil Level Sensor Ass'y | Includes 21 - 24.

278001315

Unavailable

22

Female Housing, 2 Circuits

278000217

$9.59

23

Wire Seal

278000218

$4.39

24

Male Terminal | XT Models

278000222

$3.19

25

Grommet

204470104

Unavailable

26

OIL 2T CARB PREM. MINERAL QT/0,946L This part replaces 413802900.

779119

$12.99

2T Snowmobile Premium Mineral Oil This part replaces 413803000.

779120

$43.99

OIL 2T CARB PREM. MINERAL 55 GAL/205L This part replaces 413803200.

779123

Unavailable

SYNTHETIC INJECTION OIL, 12 X 1 LITER - Call your local BRP dealership

413710500

Unavailable

OIL 2T 3X1G SYNTH - Call your local BRP dealership This part replaces 293600046.

293600133

Unavailable

OIL 2T E-TEC SYNTHETIC 55 GAL/205L This part replaces 293600047.

779130

Unavailable

27

Was 293550004 Dielectric Grease, 150 g

219704453

$38.99
