Description

Price

1

Oil Tank

275000238

$98.99

2

Elbow Fitting 90°

293710070

Unavailable

3

Grommet

293720008

$14.75

4

Oil Cap | Includes 4 - 5.

275000197

Unavailable

5

Snap Cap

293000065

Unavailable

6

Tie Wrap 94 mm | 4X4

293750001

$1.03

7

Filler Neck

275000187

Unavailable

8

Restrictor

275000190

Unavailable

9

Était/Was 293800038 Loctite 518, 50 ml

219704456

$53.99

10

Gasket

293250029

$14.82

11

Filler Neck Nut, Fuel

211100012

$14.22

12

Filler Hose

275000188

Unavailable

13

Tridon Clamp

293650035

$7.29

14

GASKET - Call your local BRP dealership This part replaces 293250075.

293250211

Unavailable

15

Oetiker Clamp

293650042

$3.09

16

HOSE-6MM. 5000MM LONG - Call your local BRP dealership

219704396

Unavailable

17

Tie Wrap 142 mm

293750002

$1.25

18

Check Valve This part replaces 275500087.

275501246

$10.99

19

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

$32.99

20

OIL FILTER - Call your local BRP dealership

275000051

Unavailable

21

Oil Level Sensor Ass'y | Includes 21 - 24.

278001187

Unavailable

22

Female Housing, 2 Circuits

278000217

$9.59

23

Wire Seal

278000218

$4.39

24

Male Terminal | XT Models

278000222

$3.19

Sea-doo GSX Limited 5625, 1998 02- Oil Injection System Diagram

Oil Tank

Elbow Fitting 90°

Grommet

Oil Cap | Includes 4 - 5.

Snap Cap

Tie Wrap 94 mm | 4X4

Filler Neck

Restrictor

Était/Was 293800038 Loctite 518, 50 ml

Gasket

Filler Neck Nut, Fuel

Filler Hose

Tridon Clamp

GASKET - Call your local BRP dealership This part replaces 293250075.

Oetiker Clamp

HOSE-6MM. 5000MM LONG - Call your local BRP dealership

Tie Wrap 142 mm

Check Valve This part replaces 275500087.

Polyurethane Hose, 8 Mm 3000Mm Long

OIL FILTER - Call your local BRP dealership

Oil Level Sensor Ass'y | Includes 21 - 24.

Female Housing, 2 Circuits

Wire Seal

Male Terminal | XT Models
