Suzuki GSF1250S (2009) REAR SWINGING ARM Diagram

#

Description
Price

1

SWINGING ARM ASSY, REAR | FOR YAY,YHL,YKZ,YMK

61000-49G10-YAP

Unavailable

1

SWINGING ARM ASSY, REAR | MODEL K7 FOR YLE MODEL K8/K9 FOR YBA,YHG; Includes Item(s) 2 - 4

61000-49G00

Unavailable

2

BEARING (25X33X35) This part replaces 09263-25059.

09263-25073

$27.91

3

.BEARING (17X24X25) This part replaces 09263-17037.

09263-17053

$19.55

4

SPACER

61282-31E00

Unavailable

5

SPACER,PIVOT BEARING

61251-31E00

$66.87

6

PLATE, RR SWGARM BRACKET

61124-33E00

$6.27

7

SCREW

02142-0616B

$1.80

8

SHAFT, PIVOT

61211-31E00

$144.57

9

WASHER

09160-18030

$2.58

10

NUT

09159-18007

$21.28

11

BUFFER, CHAIN TOUCH DEFENSE

61273-49G10

Unavailable

12

SCREW, CHAIN BUFFER

09111-06072

$2.01

13

CASE, CHAIN

61311-27E20

$298.40

14

SCREW

09136-06017

$2.39

15

SPACER, CHAIN CASE

09180-06092

$3.72

16

CUSHION (8X22X7) This part replaces 09320-08013.

09320-08509

$1.91

17

ADJUSTER, CHAIN, R This part replaces 61445-40F20.

61445-40F00

$43.20

18

ADJUSTER, CHAIN, L This part replaces 61446-40F10.

61446-40F00

$43.20

19

BOLT

09100-08287

$2.80

20

NUT

08316-1008B

$2.65
