Suzuki GSF1250S (2009) FUEL TANK (MODEL K9) Diagram

TANK ASSY, FUEL (BLACK) | E28

44100-18H00-YAY

Unavailable

TANK ASSY, FUEL (GRAY) | E28

44100-18H00-YHG

Unavailable

TANK ASSY, FUEL (BLUE) | E28

44100-18H00-YKZ

Unavailable

TANK ASSY, FUEL (RED) | E28

44100-18H00-YMK

Unavailable

TANK ASSY,FUEL( | E33 This part replaces 44100-18H20-YAY.

44100-18H51-YAY

$1,404.12

TANK ASSY, FUEL (GRAY) | E33

44100-18H20-YHG

Unavailable

TANK ASSY,FUEL( | E33 This part replaces 44100-18H20-YKZ.

44100-18H50-YKZ

Unavailable

TANK ASSY, FUEL (RED) | E33

44100-18H20-YMK

Unavailable

EMBLEM, "S"

68111-18G20

$32.30

CAP SET,FUEL TA | E28 This part replaces 44200-16850.

44200-16852

$118.21

CAP SET,FUEL TA | E33 This part replaces 44200-16870.

44200-16872

$155.42

BOLT

09106-05017

$2.83

MOLDING

68241-04X50-300

$7.32

CUSHION, FRONT

44511-27E00

$12.48

SCREW

02142-0510B

$1.78

WASHER

09169-05012

$2.38

CUSHION, SIDE

45149-45330

$3.89

CUSHION, FUEL TANK SIDE

44541-31F00

$11.53

BRACKET, REAR

44141-38G00

Unavailable

WASHER, LOWER

09169-06062

$2.50

CUSHION (8X18X10) This part replaces 09320-08001.

09320-08527

$2.06

BOLT

09116-06192

$2.30

CUSHION

45149-21G00

Unavailable

CUSHION

47163-10FA0

$4.55

BOLT

09116-06172

$2.50

CUSHION,FUEL TA This part replaces 44541-38G00.

44541-38G01

$5.22

SPACER

09180-06271

$2.35

HOSE,WATER DRAI This part replaces 44423-16G10.

44423-16G11

$10.25

GUIDE, DRAIN HOSE

44480-18H00

Unavailable

CLAMP

09404-10417

$2.72

3 WAY, DRAIN HOSE

09367-08004

$4.83

HOSE(7X10.2X600 This part replaces 09352-70103-600.

09352-70104-600

$5.63

HOSE,VACUUM This part replaces 44424-38G00.

44425-09E01

$11.28

.JOINT,3 WAY

09367-06002

$2.50

HOSE,5X10X600 This part replaces 09352-50823-600.

44421-13ER0

$10.06

HOSE This part replaces 09352-50823-00B.

09352-50005-00B

$13.93

CLAMP

09407-14403

$2.26

GAUGE ASSY,FUEL This part replaces 34810-18H00.

34810-18H01

$111.66

BOLT

01500-0612A

$1.78

HOSE & DRAIN (L:600!10)

09352-13162-600

$24.87
