Suzuki GSF1250S (2009) AIR CLEANER Diagram

#

Description
Price

1

CLEANER ASSY, AIR | Includes Item(s) 2 - 17

13700-18H00

Unavailable

2

CAP,AIR CLEANER This part replaces 13740-18H00.

13740-18H01

$65.53

3

TUBE, INLET

13891-18H00

Unavailable

4

GASKET, AIR CLEANER CAP

13746-18H00

$14.98

5

FILTER, AIR

13780-18H00

$44.38

6

GASKET, CASE

13746-18H00

$14.98

7

TUBE, BREATHER

13850-18H00

Unavailable

8

CLIP

09401-15101

$2.28

9

TUBE, DRAIN

13870-18H00

Unavailable

10

STOPPER This part replaces 13877-20F00.

13877-00190

$6.00

11

CLIP

09401-15101

$2.28

12

CLIP

09401-13409

$2.13

13

TUBE, OUTLET

13881-18H00

Unavailable

14

CLAMP

09402-54208

$5.09

15

SCREW

02142-0512A

$1.37

16

TUBE

13910-18H00

Unavailable

17

CLIP

09401-15101

$2.28

18

CLAMP

09404-10417

$2.97

19

SCREW, AIR CLEANER

01550-0612B

$2.38

20

HOSE, ISC VALVE

13697-18H00

Unavailable

21

CLIP

09401-15101

$2.28

22

CLIP

09401-17401

$1.01

23

SENSOR, BOOST | Includes Item(s) 24

15630-29G20

$315.90

24

COVER

15625-29G10

Unavailable

25

BRACKET

13166-18H00

Unavailable

26

BOLT

01550-0612A

$1.97
