Suzuki GSF1200 (2005) STEERING STEM (GSF1200K1/K2/K3) Diagram

#

Description
Price

1

STEM, STEERING | GSF1200K1/K2

51410-32F00

Unavailable

1

STEM, STEERING | GSF1200K3; Includes Item(s) 2 - 3

51410-32F10

Unavailable

2

SEAL, LOWER

51644-12C00

$9.04

3

BEARING (30X55X17) | GSF1200K1/K2 BALL BEARING

09267-30010

$44.72

3

BEARING (30X55X17) | GSF1200K3 TAPER BEARING

09265-30020

$42.08

4

BOLT

01550-08407

$4.35

5

NUT, STEERING STEM

51631-31F00

$22.42

6

SEAL,DUST This part replaces 51643-40502.

51643-40503

$6.04

7

BEARING (25X47X15) | GSF1200K1/K2

09267-25009

$56.72

7

BEARING (25X47X15) | GSF1200K3

09265-25038

$42.34

8

WASHER

51356-24B01

$7.13

9

NUT, CAP

51353-24B00

$34.62

10

HEAD, STEERING STEM

51311-32F00

Unavailable

11

BOLT

07130-08357

$3.01

12

HOLDER, HANDLE UNDER

56221-27E00

Unavailable

13

HOLDER, HANDLE UPPER

56211-32F00

Unavailable

14

BOLT

07130-08307

$4.98

15

WASHER

09164-08015

$3.00

16

CUSHION,RUBBER This part replaces 56241-27E00.

56241-27E01

$38.25

17

CUSHION RUBBER UNDER This part replaces 56242-28C60.

56242-28C61

$28.12

18

BOLT, HANDLE HOLDER

56321-27E00

$11.32

19

SPACER

56243-42A00

$9.07

20

NUT

08319-31107

$2.80

21

CAP

09250-06011

$2.62

22

BRACKET, LAMP HOUSING RH

51530-32F00

Unavailable

23

BRACKET, LAMP HOUSING LH

51540-32F00

Unavailable

24

DAMPER,HEAD LAMP HSG BRKT This part replaces 51553-15D00.

51553-15D01

$4.93

25

STAY, LAMP HOUSING RH

51851-31F00

Unavailable

26

STAY, LAMP HOUSING LH

51861-31F00

Unavailable

27

SCREW (6X12)

09139-06027

$2.00
