Suzuki GS850GL (1983) RIGHT HANDLE SWITCH Diagram

#

Description
Price

1

GRIP, THROTTLE This part replaces 57110-44011.

57110-49510

Unavailable

2

CAP, GRIP END RH

57215-49100

Unavailable

3

LEVER, BRAKE

57420-49101

$34.15

4

BOLT

57431-18621

$8.28

5

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

6

SWITCH ASSY, ST | Includes Item(s) 7 - 11 This part replaces 57460-49300.

57460-45500

$35.23

7

HOLDER

57465-18601

$4.34

8

COVER

57481-33010

$5.84

9

SCREW This part replaces 09125-03105.

09125-03105-XC0

$2.23

10

WASHER,LOCK This part replaces 08321-21038.

09162-03001

$1.49

11

WASHER This part replaces 08322-21038.

08322-01037

$1.93

12

BAND (L:120)

09407-12402

$3.04

13

SWITCH ASSY,HAN | MODEL Z This part replaces 37200-49231.

37200-49232

Unavailable

13

NO DESCRIPTION AVAILABLE | MODEL D; Includes Item(s) 14 This part replaces 37200-49590.

37200-49591

Unavailable

14

SCREW This part replaces 37591-49210.

09125-05102

$1.61

15

SWITCH ASSY,HAN | OPT,MODEL Z This part replaces 37200-49211.

37200-49212

Unavailable

15

NO DESCRIPTION AVAILABLE | OPT,MODEL D; Includes Item(s) 16 This part replaces 37200-49570.

37200-49571

Unavailable

16

SCREW | OPT This part replaces 37591-49210.

09125-05102

$1.61
