Suzuki GS700E (1985) RIGHT HANDLE SWITCH Diagram

#

Description
Price

1

GRIP, THROTTLE This part replaces 57110-49500.

57110-49501

$34.00

2

NO DESCRIPTION AVAILABLE | GS700EF This part replaces 37200-34330.

37200-345V0

Unavailable

2

NO DESCRIPTION AVAILABLE | GS700ESF; Includes Item(s) 3 - 4 This part replaces 37200-34530.

37200-345V0

Unavailable

3

.SCREW (5X25) This part replaces 02112-05255.

09125-05066

$1.65

4

SCREW This part replaces 02112-05355.

02112-0535B

$2.23

5

LEVER, BRAKE

57420-45500

Unavailable

6

BOLT

57431-49100

Unavailable

7

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

8

SWITCH ASSY, STOP | GS700EF

57460-33700

$43.37

9

SWITCH ASSY, ST | GS700ESF; Includes Item(s) 10 - 14 This part replaces 57460-49300.

57460-45500

$35.23

10

HOLDER | GS700ESF

57465-18601

$4.34

11

COVER | GS700ESF

57481-33010

$5.84

12

SCREW | GS700ESF This part replaces 09125-03105.

09125-03105-XC0

$2.23

13

WASHER,LOCK | GS700ESF This part replaces 08321-21038.

09162-03001

$1.49

14

WASHER | GS700ESF This part replaces 08322-21038.

08322-01037

$1.93
