Suzuki GS550L (1980) RIGHT HANDLE SWITCH Diagram

#

Description
Price

1

GRIP ASSY, THROTTLE | Includes Item(s) 2 - 6 This part replaces 57100-47010.

57100-47500

Unavailable

2

GRIP, THROTTLE This part replaces 57110-44011.

57110-49510

Unavailable

3

BUTTON, STARTING

57371-45000

$4.52

4

CONTACT

57372-45000

$4.45

5

SPRING

57382-45000

$3.37

6

SCREW This part replaces 02112-05258.

02112-05257

$1.49

7

CAP, GRIP AND RH

57215-49100

Unavailable

8

LEVER, BRAKE | Includes Item(s) 9 - 11 This part replaces 57300-49100.

57420-49101

$34.15

9

LEVER, BRAKE This part replaces 57420-49100.

57420-49101

$34.15

10

BOLT

57431-18621

$8.28

11

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

12

SWITCH ASSY, ST This part replaces 57460-49100.

57460-45500

$35.23

13

HOLDER | Includes Item(s) 14 - 19 This part replaces 57461-18600.

57465-18601

$4.34

14

HOLDER This part replaces 57462-18600.

57465-18601

$4.34

15

HOLDER This part replaces 57463-18600.

57465-18601

$4.34

16

COVER

57481-33010

$5.84

17

SCREW This part replaces 09125-03105.

09125-03105-XC0

$2.23

18

WASHER,LOCK This part replaces 08321-21038.

09162-03001

$1.49

19

WASHER This part replaces 08322-21038.

08322-01037

$1.93

20

BAND (L:120)

09407-12402

$3.04
