Suzuki GS550EF (1986) OIL COOLER Diagram

#

Description
Price

1

COOLER ASSY, ENGINE OIL

16600-34310

Unavailable

2

BOLT, GEAR SHIFT LINK This part replaces 01107-06205.

01500-0620A

$1.78

3

BOLT

09100-06110

Unavailable

4

LOCK WASHER This part replaces 08321-21064.

08321-0106A

$1.84

5

WASHER (6.5X18X1.6) This part replaces 09160-06039.

09160-06109

$1.49

6

SPACER (6.5X10X10) This part replaces 09180-06030.

09180-06310

$1.91

7

CUSHION

09320-10015

$2.54

8

BRACKET, OIL COOLER

16620-43400

Unavailable

9

PLUG, DRAIN This part replaces 01107-08165.

01500-0816B

$2.50

10

BOLT This part replaces 01107-08205.

01500-0820A

$2.28

11

LOCK WASHER This part replaces 08321-21084.

08321-0108A

$1.84

12

WASHER This part replaces 08322-11084.

08322-0108A

$1.92

13

HOSE, OIL COOLER LH

16460-43400

Unavailable

14

HOSE, OIL COOLER RH

16470-43400

Unavailable

15

UNION BOLT, ENGINE SIDE This part replaces 09360-14002.

09360-14005

Unavailable

16

GASKET

09168-14011

$1.85
