Suzuki GS550EF (1986) CANISTER (FOR MODEL G OF CALIFORNIA) Diagram

#

Description
Price

1

CANISTER ASSY

17210-43401

Unavailable

2

BOLT, GEAR SHIFT LINK This part replaces 01107-06205.

01500-0620A

$1.78

3

WASHER (6.5X18X1.6) This part replaces 09160-06039.

09160-06109

$1.49

4

SPACER

09180-06038

$1.98

5

CUSHION (8.5X20X8) This part replaces 09320-08007.

09320-08510

$1.97

6

PLATE, CANISTER FITTING | Includes Item(s) 7

17230-43400

Unavailable

7

BAND

09462-00033

$3.20

8

NUT This part replaces 08316-26066.

08316-1006B

$2.50

9

PIPE, CANISTER

17280-43401

Unavailable

10

VALVE, FUEL TANK BREATHER

44240-38A00

$61.15

11

PLATE,FUEL TANK BREATHER NO.2

44892-24A00

$4.52

12

SCREW This part replaces 02142-04105.

02142-0410A

$1.49

13

HOSE, PIPE/VALVE JOINT

17261-43400

Unavailable

14

HOSE, VALVE/CANISTER JOINT

17262-43401

Unavailable

15

HOSE, CANISTER/PIPE JOINT

17263-43401

Unavailable

16

HOSE, JOINT/FUEL TANK

17264-43400

Unavailable

17

HOSE, JOINT/CARBURETOR

17265-43400

Unavailable

18

CUSHION

17251-43400

Unavailable

19

WASHER,8.5X16X2 This part replaces 09160-08050.

09160-08144

$2.72

20

CLIP This part replaces 09401-11410.

09401-11413

$2.26

21

CLIP This part replaces 09401-12406.

09401-11415

$2.23

22

CLAMP

09407-11401

$2.63

23

CLAMP

09407-18402

$2.19
