Description

Price

1

PAN, OIL

11511-44100

$102.17

2

GASKET, OIL PAN

11489-44110

$10.28

3

BOLT This part replaces 01550-06303.

01550-0630A

$2.32

4

PLUG (MAGNETO) | MODEL V/W This part replaces 09247-14001.

09247-14002

$5.24

4

PLUG, OIL DRAIN | MODEL X/Y

09247-14026

$3.76

5

GASKET

09168-14002

$2.26

6

VALVE ASSY, OIL RELIEF | MODEL V This part replaces 16440-05C01.

16440-11D00

$59.07

6

REGULATOR, OIL | MODEL W/X/Y

16440-11D00

$59.07

7

FILTER, ENGINE OIL

16510-45040

$5.96

8

O RING

16518-45000

$5.70

9

SPRING

09440-32004

$2.92

10

CAP, ENGINE OIL FILTER

16512-45D00

$56.93

11

STUD BOLT This part replaces 01421-06208.

01421-0620A

$1.91

12

NUT This part replaces 08313-20063.

08313-2006A

$1.97

13

STRAINER, ENGINE OIL

16520-01D01

Unavailable

14

BOLT This part replaces 01570-06123.

01570-0612A

$2.63

15

PUMP ASSY, ENGINE OIL

16400-44100

$198.45

16

O RING (D:1.9,ID:13)

09280-13004

$2.17

17

SCREW This part replaces 02112-06253.

02112-0625A

$1.80

18

GEAR, DRIVEN (NT:27)

16331-01D10

$68.60

19

WASHER (10X18X0.5)

09181-10158
