Suzuki GS500 (2002) FRAME COVER (MODEL K2) Diagram

#

Description
Price

1

COVER, FRAME RH (SILVER) | FOR Y7L

47110-01DK0-YD8

Unavailable

1

COVER, FRAME RH (SILVER) | FOR YC2; Includes Item(s) 2 - 3

47110-01DK0-YUX

Unavailable

2

TAPE SET, RH | FOR YD8

68130-01D90-FP2

Unavailable

2

TAPE SET, RH | FOR YUX

68130-01D90-GZ8

Unavailable

3

TAPE, RH

68135-01D40-HJ5

Unavailable

4

COVER, FRAME LH (SILVER) | FOR Y7L

47210-01DK0-YD8

Unavailable

4

COVER, FRAME LH (SILVER) | FOR YC2; Includes Item(s) 5 - 6

47210-01DKO-YUX

Unavailable

5

TAPE SET, LH | FOR YD8

68140-01D90-FP2

Unavailable

5

TAPE SET, LH | FOR YUX

68140-01D90-GZ8

Unavailable

6

TAPE LH

68145-01D40-HJ5

Unavailable

7

BOLT

09116-06010

$2.19

8

SPACER

09180-06263

$2.03

9

CUSHION

09320-09016

$1.97

10

COVER, CENTER (SILVER) | Includes Item(s) 11

47310-01D50-YD8

Unavailable

11

EMBLEM (BLACK)

68165-01D00-Y7L

Unavailable

12

COVER, LOWER This part replaces 47321-01DA0.

47321-01DA0-NE2

$113.15

13

SCREW This part replaces 03541-04103.

03541-0410A

$1.68

14

CUSHION

09320-08018

$3.04
