Suzuki GS450L (1983) RIGHT HANDLE SWITCH Diagram

#

Description
Price

1

GRIP, THROTTLE This part replaces 57110-44011.

57110-49510

Unavailable

2

CAP, GRIP END RH

57215-49100

Unavailable

3

LEVER, BRAKE

57420-49101

$34.15

4

BOLT

57431-18621

$8.28

5

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

6

SWITCH ASSY, HANDLE RH | Includes Item(s) 7 - 8

37200-34230

Unavailable

7

SCREW This part replaces 02112-05258.

02112-05257

$1.49

8

SCREW This part replaces 02112-05358.

02112-05357

$1.49

9

SWITCH ASSY, ST | Includes Item(s) 10 - 14 This part replaces 57460-49300.

57460-45500

$35.23

10

HOLDER, CONTACT

57465-18601

$4.34

11

COVER

57481-33010

$5.84

12

SCREW This part replaces 09125-03105.

09125-03105-XC0

$2.23

13

WASHER,LOCK This part replaces 08321-21038.

09162-03001

$1.49

14

WASHER This part replaces 08322-21038.

08322-01037

$1.93

15

BAND (L:120)

09407-12402

$3.04
