Suzuki GS450L (1983) FRONT WHEEL Diagram

#

Description
Price

1

WHEEL (BLACK)

54111-45300-291

Unavailable

2

BEARING This part replaces 08123-63027.

08123-6302B

$22.74

3

SPACER

54730-18400

$20.45

4

AXLE,FRONT This part replaces 54711-33002.

54711-3300V

Unavailable

5

NUT This part replaces 08314-31128.

08314-3112A

$2.41

6

PIN This part replaces 04111-30308.

04111-3030A

$1.49

7

SPACER, BEARING

54740-18410

$20.45

8

SPACER, AXLE (15X22X30)

09180-15034

Unavailable

9

WASHER This part replaces 08322-21128.

08322-01127

$1.84

10

COVER, RH

54871-45000

$8.98

11

BOX ASSY,SPEEDO This part replaces 54600-45200.

54600-49101

$105.57

12

DISK, FRONT BRAKE

59211-45200

Unavailable

13

BOLT

09100-08140

$2.10

14

WASHER

09169-08016

$2.41

15

TIRE, FRONT (90/90-19.52S) | IRC

55100-44310

Unavailable

15

TIRE, FRONT (90/90-19.52S) | BS

55100-44930

Unavailable

16

TUBE, INNER FRONT

55200-29010

Unavailable

17

BALANCER, WHEEL NO.2 This part replaces 55411-45100.

55412-17G00

$7.05

17

BALANCER, NO.2

55412-45100

Unavailable

17

BALANCER (10G) This part replaces 55413-45100.

55411-00A00

$1.49
