Suzuki GS450ET (1982) SEAT TAIL COVER (MODEL T) Diagram

#

Description
Price

1

TAIL COVER, SEAT (BLACK)

45511-44101-019

Unavailable

2

TAPE SET

68160-44110-72B

Unavailable

3

TAIL COVER, SEAT (BLACK) This part replaces 45511-44101-05N.

45511-44101-019

Unavailable

4

TAPE SET

68160-44110-72B

Unavailable

5

EMBLEM

68166-49200-998

Unavailable

6

TAIL COVER, SEAT (BLACK) | GS450ST This part replaces 45511-44101-00J.

45511-44101-019

Unavailable

7

TAPE SET | GS450ST

68160-44120-70N

Unavailable

8

EMBLEM,SEAT TAI | GS450ST This part replaces 68166-49200-538.

68166-49201-538

Unavailable

9

BRACKET, SEAT TAIL COVER This part replaces 45530-44102.

45530-44103

Unavailable

10

BOLT M8X16 This part replaces 01517-08168.

01550-08167

$2.85

11

WASHER (8.5X22X2) This part replaces 09160-08007.

09160-08127

$2.12

12

HANDLE, PILLION RIDER

46210-44100

Unavailable

13

CUSHION

46212-49000

Unavailable

14

END, HANDLE

46213-49000

Unavailable

15

BOLT This part replaces 01107-08308.

01500-08307

$3.04

16

.LOCK WASHER This part replaces 08321-21088.

08321-01087

$2.13

17

WASHER This part replaces 08322-11088.

08322-01087

$2.13

18

GROMMET

45522-49200

$4.58

19

LOCK SET, SEAT This part replaces 95700-49820.

95700-49830

Unavailable

20

BOLT This part replaces 01107-06128.

01500-06127

$1.97

21

LOCK WASHER This part replaces 08321-21068.

08321-01067

$2.13

22

WASHER This part replaces 08322-21068.

08322-01067

$2.13

23

BOX, SEAT TAIL

94990-44100

Unavailable

24

LID, SEAT TAIL BOX

94992-44100

Unavailable

25

WASHER This part replaces 08322-21068.

08322-01067

$2.13

26

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

27

CARRIER, SPORTS | OPT

46310-44100

Unavailable
