Suzuki GS450ET (1982) SEAT (MODEL T) Diagram

#

Description
Price

1

NO DESCRIPTION AVAILABLE This part replaces 45100-44112-41G.

45100-44104-48G

Unavailable

2

CUSHION

09321-08009

$3.05

3

CUSHION

09321-08010

$3.85

4

STRIKER, SEAT LOCK

45210-44101

Unavailable

5

PLATE

45217-44100

Unavailable

6

WASHER This part replaces 08322-21068.

08322-01067

$2.13

7

LOCK WASHER This part replaces 08321-21068.

08321-01067

$2.13

8

.NUT This part replaces 08310-22068.

08310-00067

$2.13

9

MOULDING, RH (BLACK)

45191-44101-019

Unavailable

9

NO DESCRIPTION AVAILABLE | F.NO.504899~ This part replaces 45191-44102-019.

45191-44102-13L

Unavailable

10

MOULDING, LH (BLACK)

45192-44101-019

Unavailable

10

NO DESCRIPTION AVAILABLE | F.NO.504899~ This part replaces 45192-44102-019.

45192-44102

Unavailable

11

NO DESCRIPTION AVAILABLE This part replaces 68101-44840-72B.

68101-44841-72B

Unavailable

12

MOULDING, RH (MAROON)

45191-44101-05N

Unavailable

12

NO DESCRIPTION AVAILABLE | F. NO. 504899~ This part replaces 45191-44102-05N.

45191-44102-13L

Unavailable

13

NO DESCRIPTION AVAILABLE This part replaces 45192-44101-05N.

45192-44101-737

Unavailable

13

MOULDING, LH (MAROON) | F.NO.504899~

45192-44102-05N

Unavailable

14

NO DESCRIPTION AVAILABLE This part replaces 68101-44840-72B.

68101-44841-72B

Unavailable

15

MOULDING, RH (RED) | GS450ST

45191-44101-00J

Unavailable

15

NO DESCRIPTION AVAILABLE | GS450ST; F.NO.504899~ This part replaces 45191-44102-00J.

45191-44102-13L

Unavailable

16

NO DESCRIPTION AVAILABLE | GS450ST This part replaces 45192-44101-00J.

45192-44101-737

Unavailable

16

NO DESCRIPTION AVAILABLE | GS450ST; F.NO.504899~ This part replaces 45192-44102-00J.

45192-44102

Unavailable

17

NO DESCRIPTION AVAILABLE | GS450ST This part replaces 68101-44850-70N.

68101-44851-70N

Unavailable

18

NUT This part replaces 09148-06005.

09148-06008

$1.49

19

LOCK SET, HELME This part replaces 95700-35821.

95700-49850

Unavailable

20

BOLT, NO.3 This part replaces 09106-06024.

07130-0610B

$3.21

21

LOCK WASHER This part replaces 08321-21068.

08321-01067

$2.13
