1979 Suzuki GS425L Crankshaft Balancer Diagram

← All diagrams

Find the part on the Crankshaft Balancer diagram for your 1979 Suzuki GS425L, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1979 Suzuki GS425L Crankshaft Balancer Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

BALANCER, CRANKSHAFT | Includes Item(s) 2 - 9

12650-44000

1
Out of stock

2

BEARING, RH

09262-30016

1
Out of stock

3

1

$69.43

In stock

4

BALANCER SHAFT SET

12600-44820

1
Out of stock

5

GEAR, DRIVEN (NT:46) | NT:46 This part replaces 12666-44000.

12666-44001

1
Out of stock

6

WASHER

09160-31001

2
Out of stock

7

SPRING

09440-15007

3
Out of stock

8

PIN

09201-08001

6
Out of stock

9

NO DESCRIPTION AVAILABLE This part replaces 08211-30422.

09181-30212

1
Out of stock

10

WASHER This part replaces 09160-12034.

09160-12076

1
Out of stock

11

1

$4.22

In stock

12

C RING

09390-62009

1

$5.10

In stock

13

PLATE, OIL RESERVE

12699-44000

1
Out of stock

14

1

$1.55

In stock

15

1

$2.28

In stock
