Suzuki GS400X (1978) FRONT HUB (35400C) Diagram

#

Description
Price

1

NO DESCRIPTION AVAILABLE This part replaces 54111-47000.

54111-47002

Unavailable

2

BEARING This part replaces 08123-63020.

08123-6302B

$22.74

3

SPACER

54730-18400

$20.45

4

AXLE,FRONT This part replaces 54711-33002.

54711-3300V

Unavailable

5

NUT This part replaces 08314-31128.

08314-3112A

$2.41

6

PIN This part replaces 04111-30308.

04111-3030A

$1.49

7

SPACER, AXLE, RH This part replaces 54740-18401.

54740-18402

Unavailable

8

SPACER, AXLE | 15x22x30

09180-15034

Unavailable

9

WASHER This part replaces 08322-21128.

08322-01127

$1.84

10

COVER, RH

54871-45000

$8.98

11

COVER, LH

54871-45010

Unavailable

12

BOX ASSY,SPEEDO This part replaces 54600-18402.

54600-18403

Unavailable

13

DISK, FRONT BRAKE

59211-44000

Unavailable

14

BOLT | 8x35

09100-08140

$2.10

15

WASHER

09169-08016

$2.41
