Suzuki GS400X (1978) ELECTRICAL Diagram

#

Description
Price

1

RELAY ASSY,STAR | C This part replaces 31800-37020.

31800-37021

$71.42

2

SCREW | C This part replaces 02112-06088.

02112-06087

$1.49

3

.NUT | C This part replaces 08310-22068.

08310-00067

$2.13

4

LOCK WASHER | C This part replaces 08321-21068.

08321-01067

$2.13

5

LEAD WIRE, STARTING MOTOR | C This part replaces 33850-24102.

33850-47010

Unavailable

6

CAP, STARTER MOTOR | C This part replaces 31861-35100.

31861-48B10

$6.55

7

CLIP | C

09408-00002

$2.30

8

REGULATOR, VOLTAGE | C,XC

32500-45021

Unavailable

9

SCREW | C,XC This part replaces 02112-06108.

02112-06107

$1.49

10

CLAMP | C,XC This part replaces 09404-06401.

09404-06039

$1.74

11

FUSE CASE ASSY | C,XC; Includes Item(s) 12 This part replaces 36740-15010.

36740-15011

$9.38

12

FUSE | C,XC; 15A

09481-15001

$2.06

13

RECTIFIER | C,XC

32800-44010

Unavailable

14

.NUT | C,XC This part replaces 08310-11068.

08310-00067

$2.13

15

LOCK WASHER | C,XC This part replaces 08321-21068.

08321-01067

$2.13

16

SCREW | C,XC This part replaces 02112-06258.

02112-06257

$1.78

17

NO DESCRIPTION AVAILABLE | C,XCC,XC This part replaces 33410-44020.

33410-44021

Unavailable

17

NO DESCRIPTION AVAILABLE | C,XCC,XC This part replaces 33420-44020.

33410-44021

Unavailable

18

SCREW | C,XC This part replaces 02112-05108.

02112-05107

$1.49

19

CONDENSER | C,XC

33421-44020

Unavailable
