1983 Suzuki GS300L Right Handle Switch Diagram

← All diagrams

Find the part on the Right Handle Switch diagram for your 1983 Suzuki GS300L, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1983 Suzuki GS300L Right Handle Switch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GRIP, THROTTLE This part replaces 57110-44010.

57110-49510

1
Out of stock

2

SWITCH ASSY, HANDLE RH This part replaces 37200-49430.

37200-49471

1
Out of stock

2

SWITCH ASSY,HAN | OPT; Includes Item(s) 3 This part replaces 37200-49410.

37200-49212

1
Out of stock

3

2

$1.86

In stock

4

LEVER ASSY, BRAKE | Includes Item(s) 5 - 11 This part replaces 57300-38220.

57300-11900

1
Out of stock

5

LEVER, BRAKE

57420-26400

1
Out of stock

6

1

$6.47

In stock

7

.NUT This part replaces 08319-21068.

08319-2106A

1
Out of stock

8

1

$2.22

In stock

9

ADJUSTER, CABLE

57441-11010

1

$5.60

In stock

10

NUT

57442-11010

1

$2.92

In stock

11

1

$42.37

In stock

12

BAND

09407-12402

2
Out of stock

13

BUTTON, STARTER | NOT SHOWN

37311-49000

1
Out of stock

14

SPRING | NOT SHOWN This part replaces 37312-49000.

57382-47500

1
Out of stock

15

CONTACT | NOT SHOWN

37313-49000

1
Out of stock
