Partiron

Suzuki GS300L (1983) RIGHT HANDLE SWITCH (MODEL D) Diagram

#

Description
Price

1

GRIP, THROTTLE This part replaces 57110-44011.

57110-49510

Unavailable

2

SWITCH ASSY, HANDLE RH This part replaces 37200-34430.

37200-34230

Unavailable

2

NO DESCRIPTION AVAILABLE | OPT; Includes Item(s) 3 - 4 This part replaces 37200-34411.

37200-45211

Unavailable

3

SCREW This part replaces 02112-05258.

02112-05257

$1.49

4

SCREW This part replaces 02112-05358.

02112-05357

$1.49

5

LEVER ASSY, BRAKE | Includes Item(s) 6 - 12 This part replaces 57300-38220.

57300-11900

Unavailable

6

LEVER, BRAKE

57420-26400

Unavailable

7

BOLT This part replaces 57431-11011.

57431-11013

$6.31

8

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

9

SCREW This part replaces 02112-06208.

02112-06207

$1.78

10

ADJUSTER, CABLE

57441-11010

$5.62

11

NUT

57442-11010

$2.79

12

SWITCH ASSY, STOP This part replaces 57460-10300.

57460-10400

$37.53

13

BAND

09407-12402

$3.04
