Suzuki GS250T (1981) OIL FILTER - OIL PUMP Diagram

#

Description
Price

1

PAN, OIL

11511-11400

Unavailable

2

GASKET,OIL PAN( This part replaces 11489-11400.

11489-11400-H17

Unavailable

3

BOLT This part replaces 01517-06258.

01550-06257

$2.31

4

BOLT This part replaces 01517-06208.

01550-06207

$2.31

5

PLUG (MAGNETO) This part replaces 09247-14001.

09247-14002

$4.73

6

GASKET

09168-14004

$1.69

7

VALVE ASSY, OIL RELIEF This part replaces 16440-44100.

16440-11D00

$66.67

8

WASHER

08212-14181

Unavailable

9

FILTER, ENGINE OIL

16510-45040

$5.30

10

O RING

16518-45000

$5.23

11

SPRING

09440-32004

$3.22

12

CAP, ENGINE OIL FILTER This part replaces 16512-45100.

16512-45101

Unavailable

13

STUD BOLT This part replaces 01421-06208.

01421-0620A

$1.89

14

NUT, LICENSE HOLDER This part replaces 08313-11068.

08313-10067

$1.83

15

WASHER This part replaces 08322-21068.

08322-01067

$1.86

16

STRAINER, ENGINE OIL

16520-11400

Unavailable

17

SCREW This part replaces 02112-06128.

02112-06127

$1.83

18

PUMP, ENGINE OIL

16400-44100

$220.83

19

O RING

09280-13004

$2.19

20

SCREW This part replaces 02112-06258.

02112-06257

$1.68

21

GEAR, DRIVEN (NT:25)

16331-11400

Unavailable

22

WASHER

08221-10185

$2.35

23

PIN

09261-04009

$1.50

24

CIRCLIP

08331-31109

$1.77
