Description

Price

1

GRIP, LH

57211-49500

$13.95

2

LEVER ASSY,CLUT | Includes Item(s) 3 - 14 This part replaces 57500-49300.

57500-49301

Unavailable

3

LEVER, CLUTCH

57620-49101

Unavailable

4

BOLT This part replaces 57431-11011.

57431-11013

$6.31

5

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

6

WIRING HARNESS

57540-49300

Unavailable

7

HOLDER

57465-18601

$4.34

8

COVER

57481-33010

$5.84

9

SCREW This part replaces 09125-03105.

09125-03105-XC0

$2.23

10

WASHER,LOCK This part replaces 08321-21038.

09162-03001

$1.49

11

WASHER This part replaces 08322-21038.

08322-01037

$1.93

12

ADJUSTER, CABLE

57441-11010

$5.62

13

NUT

57442-11010

$2.79

14

BOLT

57451-49100

Unavailable

15

COVER

57661-31000

$7.25

16

BOOT, CLUTCH CABLE This part replaces 58273-31000.

58273-31001

$2.22

17

SWITCH ASSY,HAN | Includes Item(s) 18 This part replaces 37400-49331.

37400-45373

Unavailable

18

SCREW This part replaces 02112-05168.

02112-05167

$1.97

Suzuki GS1100S (1983) LEFT HANDLE SWITCH Diagram

GRIP, LH

LEVER ASSY,CLUT | Includes Item(s) 3 - 14 This part replaces 57500-49300.

LEVER, CLUTCH

BOLT This part replaces 57431-11011.

.NUT This part replaces 08319-21068.

WIRING HARNESS

HOLDER

COVER

SCREW This part replaces 09125-03105.

WASHER,LOCK This part replaces 08321-21038.

WASHER This part replaces 08322-21038.

ADJUSTER, CABLE

NUT

BOLT

COVER

BOOT, CLUTCH CABLE This part replaces 58273-31000.

SWITCH ASSY,HAN | Includes Item(s) 18 This part replaces 37400-49331.

SCREW This part replaces 02112-05168.
