Suzuki GS1000G (1981) FUEL COCK Diagram

#

Description
Price

1

COCK ASSY,FUEL | Includes Item(s) 2 - 4 This part replaces 44300-45011.

44300-45012

Unavailable

2

V SEAL,FUEL COC This part replaces 44353-33154.

44353-33155

$5.25

3

GASKET This part replaces 44341-33150.

44341-33151

$2.19

4

O RING

44348-31051

Unavailable

5

BOLT This part replaces 09128-06006.

09128-06057

$1.65

6

GASKET (5.8X13X1.2) This part replaces 09168-06010.

09168-06023

$2.35

7

HOSE(7X10.2X200 This part replaces 09343-07026.

09352-70104-00B

$15.32

8

CLIP

09401-10403

$1.65

9

SPRING This part replaces 09440-13018.

09440-13043

$6.04

10

GAUGE ASSY, FUEL LEVEL | Includes Item(s) 11

34810-45100

Unavailable

11

GASKET

34825-45100

$5.80

12

BOLT This part replaces 01104-05108.

01500-0510B

$1.80

13

LOCK WASHER This part replaces 08321-21058.

08321-0105A

$1.84

14

PLATE This part replaces 34885-49002.

34885-49005

Unavailable

15

GASKET,FUEL DRA This part replaces 34888-49000.

34888-49001

Unavailable

16

SCREW This part replaces 02112-05088.

02112-05087

$1.49

17

LOCK WASHER This part replaces 08321-21058.

08321-0105A

$1.84

18

HOSE This part replaces 09343-05165.

09352-50005-00B

$13.93

19

CLIP

09401-08402

$1.49
