10- Rear Electrical Box
Sea-doo GS, 5846/5847, 1999 10- Rear Electrical Box Diagram
#
1
Base
278001191
Unavailable
2
Cover
278001265
Unavailable
3
Ground Plate
278000732
Unavailable
4
IGNITION COIL - Call your local BRP dealership
278001130
Unavailable
5
Mounting Plate
278001193
Unavailable
6
GASKET - Call your local BRP dealership
278000440
Unavailable
7
Gasket
293200030
Unavailable
8
Tie Wrap 142 mm
293750002
$1.25
9
Was 293550004 Dielectric Grease, 150 g
219704453
$38.99
10
HEX. PLASTITE SCREW M5.28 X 16 - Call your local BRP dealership
243041660
Unavailable
11
Flat Washer 5 mm, Stainless
234052600
$0.77
12
WASHER-LOCK IMPERIAL - Call your local BRP dealership
211200043
Unavailable
13
Loctite 271, 10 ml
293800005
$26.99
14
Stainless Flat Washer M6
234061600
$0.33
15
Grommet
278000682
Unavailable
16
Starter Relay
278003012
$42.49
17
Hex. Elastic Stop Nut M6
232561600
$1.15
18
Hex. Flange Screw M6 X 10
210261040
$1.48
19
Rear Electric Box Harness | Includes 19 - 27.
278000861
Unavailable
20
Sealing Cap
293000052
$3.19
21
Male Connector, 2 Circuits
278001113
$16.86
22
Female Terminal
278001114
$3.19
23
Male Terminal Housing, 6 Circuits
710001539
$19.99
24
Female Lock, 6 Circuits
278000735
$3.19
25
Male Terminal
278000631
$4.39
26
Male Terminal
278000230
$4.39
27
Ring Terminal
278000300
Unavailable
28
Fuse Harness 15 Amp | Includes 28 - 34.
278000665
Unavailable
29
Fuse Holder Cap
278001326
$7.69
30
Fuse, 15 Amperes
278000343
$3.28
31
Female Terminal | DS 650 X
278001009
$3.19
32
Insulated Sheath
278001007
$3.58
33
Cushion
278000805
$3.28
34
Ring Terminal
278000300
Unavailable
35
Flat Washer, Emhart
213200016
$0.72
36
Ground Harness | Includes 82 - 84.
278000664
Unavailable
37
FEMALE TERMINAL - Call your local BRP dealership
278000228
Unavailable
38
Ring Terminal
278000300
Unavailable
39
Battery 19A | Includes 5 to 8
278001756
$153.36
40
FLAT WASHER 6 MM - Call your local BRP dealership
211200018
Unavailable
41
Hex. Screw M6 X 16
207161644
$0.74
42
Hex. Nut M6
232061414
$0.53
43
STRAP - Call your local BRP dealership
293850031
Unavailable
44
3 WIRE SUPPORT - Call your local BRP dealership
278000245
Unavailable
45
Tie Wrap 142 mm
293750002
$1.25
46
Engine Harness | RX DI 5591/5592.
278000511
Unavailable
47
Electric Wire Cap
278000100
Unavailable
48
GROMMET - Call your local BRP dealership
278000098
Unavailable
49
PROTECTION CAP - Call your local BRP dealership
278000020
Unavailable
50
Battery Lower Pad
278001234
Unavailable
51
Battery Ground Cable
278001097
Unavailable
52
NGK Spark Plug BR8ES This part replaces 278000609.
219703119
$4.23
53
Hex. Elastic Stop Nut M6
232561600
$1.15
54
Temperature Sensor
278000965
$73.99
55
Était/Was 293800038 Loctite 518, 50 ml
219704456
$53.99
56
SPARK PLUG WIRE - Call your local BRP dealership This part replaces 278001268.
278002198
Unavailable
57
SPARK PLUG WIRE - Call your local BRP dealership This part replaces 278001268.
278002198
Unavailable
58
PROTECTION CAP - Call your local BRP dealership
278000020
Unavailable
59
Starter Cable (Red) | Includes 59 - 62.
278000975
Unavailable
60
Electric Wire Cap
278000100
Unavailable
61
GROMMET - Call your local BRP dealership
278000098
Unavailable
62
PROTECTION CAP - Call your local BRP dealership
278000020
Unavailable
63
SPARK PLUG CAP - Call your local BRP dealership
278000237
$16.99
64
Stainless, Flat Washer 8 mm
234081600
$0.55
65
TOOTHED LOCK WASHER - Call your local BRP dealership
234381608
Unavailable
66
HEX. SCREW M8 X 20 - Call your local BRP dealership
207182060
Unavailable
67
Electric Wire Cap
278000100
Unavailable
68
Tie Wrap 94 mm | 4X4
293750001
$1.03
69
14 X 1 UNSL HX WSHR T/AB BLK ZINC - Call your local BRP dealership This part replaces 250000005.
296000365
Unavailable
70
Pop Rivet 3/16"
293150005
$0.52
71
COLLAR SUPPORT - Call your local BRP dealership
278000559
Unavailable
72
Tie-Rap 173 mm
293750009
$1.04
