Sea-doo GS, 5846/5847, 1999 Oil Injection System Diagram

#

Description
Price

1

Oil Tank

275000238

$76.67

2

OIL CAP - Call your local BRP dealership | Includes 17 to 18

275000221

Unavailable

3

Snap Cap, Black

293000076

Unavailable

4

Filler Neck

275000187

Unavailable

5

Gasket

293250029

$12.06

6

Filler Neck Nut, Fuel

211100012

$10.02

7

OIL LEVER SENSOR ASS'Y - Call your local BRP dealership

278001401

Unavailable

8

Wire Seal

278000218

$3.48

9

Male Terminal | XT Models

278000222

$2.55

10

Female Housing, 2 Circuits

278000217

$7.59

11

Grommet

293720008

$10.91

12

FITTING ELBOW 90 - Call your local BRP dealership

293710051

Unavailable

13

Was 275500008 Hose 12 mm

219704356

$5.94

14

Tie Wrap 94 mm | 4X4

293750001

$0.83

15

Tie Wrap 142 mm

293750002

$0.88

16

Tridon Clamp

293650035

$5.80

17

Tridon Gear Clamp

293650170

$1.74

18

HOSE-6MM. 5000MM LONG - Call your local BRP dealership

219704396

Unavailable

19

Check Valve

275500398

$8.57

20

Polyurethane Hose, 8 Mm 3000Mm Long

219704412

$27.27

21

OIL FILTER - Call your local BRP dealership

275000051

Unavailable

22

Oetiker Clamp

293650042

$1.40

23

Grommet

293720008

$10.91

24

GASKET - Call your local BRP dealership This part replaces 293250075.

293250211

Unavailable

25

Restrictor

275000190

Unavailable

26

Était/Was 293800038 Loctite 518, 50 ml

219704456

$48.48

27

Filler Hose

275000188

Unavailable

28

Norma Clamp

293650084

$3.88
