Honda GROM1252AC (15) MOTORCYCLE, THA, VIN# MLHJC611-F5100001 CLUTCH Diagram

ROTOR, OIL FILTER

15431-K26-900

$44.43

GASKET, OIL FILTER COVER

15439-K26-901

$2.92

COVER, OIL FILTER

15441-K26-900

$8.77

PLATE, OIL SEPARATOR

15661-K26-900

$5.57

CLUTCH OUTER

22100-KPG-T00

$177.74

GUIDE, CLUTCH (OUTER)

22115-KPH-900

$1.98

COLLAR, CLUTCH (OUTER)

22116-KPG-T00

$1.95

CENTER, CLUTCH

22120-KPG-T00

$25.67

DISK, CLUTCH FRICTION

22201-KPG-T00

$8.11

DISK B, CLUTCH FRICTION

22205-KPG-T00

$8.56

PLATE, CLUTCH | Use up to Engine SN 2218284.

22321-KE8-000

$12.71

PLATE, CLUTCH | Use from Engine SN 2218285.

22321-KPG-T00

$4.13

PLATE, CLUTCH PRESSURE

22350-KPG-T00

$17.55

PLATE, CLUTCH LIFTER

22361-KPG-T00

$9.41

SPRING, CLUTCH

22401-KPH-900

$1.67

ROD, CLUTCH LIFTER

22847-K26-900

$8.53

BOLT, SPECIAL FLANGE (6X20)

90050-KPH-900

$1.49

NUT, LOCK (14MM)

90231-087-010

$3.80

NUT, LOCK (14MM) This part replaces 90231-KM7-700.

90231-KM7-701

$3.78

NUT, LOCK (14MM)

90231-KM7-701

$3.78

WASHER, THRUST (17MM)

90403-KPH-900

$1.49

WASHER (14.2X26X3)

90432-KPT-A00

$1.85

BOLT, FLANGE (6X14) (Honda Code 2410884)

95701-06014-00

$1.49

BOLT, FLANGE (6X16) (Honda Code 2410892)

95701-06016-00

$1.55

BEARING, RADIAL BALL (6200)

96100-62000-00

$9.08
