Ski-Doo GRAND TOURING - 2-STROKE, 2017 Luggage Rack - Package LE Diagram

#

Description
Price

1>1b

RH Arm Ass'y

511000631

$86.12

1>1b

LH Arm Ass'y

511000632

Unavailable

1a

Square Nut M6

232862412

$1.18

1b

Torx-Truss Pt K40 X 16

250000759

$1.74

2

Nut Welded, M6

293100003

$6.32

4>4a

Rack Ass'y

511000530

$71.51

4a

Panel Nut M6 X 1.0

250100198

$1.73

5

Cover

511000545

$73.82

6

RH Tail Light Ass'y

515176849

$61.99

7

LH Tail Light Ass'y

515176850

$61.99

8

Hex. Flange Screw M6 X 30, Scotch Grip

207563044

$3.61

9

Hex. Flange Screw M6 X 25

207662554

$1.48

10

Harness

515178022

Unavailable

11

Grommet

517303756

$3.15

12

Radiator Cover

511000861

$53.99

13

Hex. Flange Screw K50 X 2.24 X 16

241151640

$1.20

14

Edge Clip

517302785

$0.70

15

WARNING DECAL - Call your local BRP dealership

516006912

Unavailable

16

WARNING DECAL, SECURITY - Call your local BRP dealership

516004603

Unavailable

17

Red RH Rear Reflector

520000731

$13.77

18

Red LH Rear Reflector

520000732

$13.38

19

BRP Logo 68mm

516008739

$12.87

20

WARNING DECAL - Call your local BRP dealership

516005523

Unavailable

21

Red RH Rear Reflector

520000729

$13.77

22

RED LH REAR REFLECTOR - Call your local BRP dealership

520000730

Unavailable

25

Torx Screw M8 X 16

250000751

$4.64

60

Torx Truss Screw M6 X 16

250000721

$1.39

390

Pop Rivet 3/16"

293150103

$0.54
