1986 Kawasaki GPZ Brake Pedal Diagram

← All diagrams

Find the part on the Brake Pedal diagram for your 1986 Kawasaki GPZ, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1986 Kawasaki GPZ Brake Pedal Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

43001

LEVER-BRAKE,PEDAL

43001-1113

1
Out of stock

43004

SHAFT-BRAKE

43004-1050

1

$49.33

In stock

92002

BOLT,FLANGED,10X41

92002-1066

1
Out of stock

92015

NUT,8MM

92015-1364

1

$3.12

In stock

92015A

NUT,LOCK,10MM

92015-1376

1

$7.71

In stock

92027

COLLAR,REAR CALIPER,L

92027-1572

1
Out of stock

92081

SPRING,BRAKE PEDAL

92081-1604

1
Out of stock

115

BOLT-SMALL-UPSET

115X0816

1
Out of stock

130

BOLT-FLANGED,8X25

130Y0825

1
Out of stock
