Yamaha GP1300CB (GP1300R) F1G11 2003 OIL TANK Diagram

#

Description
Price

1

HOSE, AIR VENT 3

F0X-U7856-00-00

Unavailable

2

. ROLL OVER VALVE

FJ0-67766-00-00

Unavailable

3

CLAMP COMP (EU0)

90600-91736-00

$8.49

4

RIVET, BLIND

90267-489U6-00

Unavailable

5

CLAMP

90464-32801-00

Unavailable

6

CLAMP

90465-10098-00

Unavailable

7

TANK, OIL

F0D-U775B-02-00

Unavailable

8

FILTER

F0D-6775C-01-00

Unavailable

9

PACKING (T:10MM)

F0D-6775E-01-00

Unavailable

10

CLAMP

90465-10098-00

Unavailable

11

PACKING, OIL CAP

GJ3-U778C-00-00

Unavailable

12

PACKING,OIL FILLER

F0X-U778E-01-00

Unavailable

13

CAP, OIL FILLER

F0X-U778B-00-00

Unavailable

14

SOCKET, OIL FILLER

F0X-U778D-00-00

Unavailable

15

CHAIN BALL

EU0-U7835-00-00

Unavailable

16

SCREW,TAPPING (EU0)

97780-40110-00

Unavailable

17

. RIVET, BLIND

90267-40935-00

Unavailable

18

NUT, OIL FILLER

F0X-U778H-01-00

Unavailable

19

HOSE,OIL FILLER

F0X-U776C-10-00

Unavailable

20

BAND, HOSE 52

90601-152U3-00

Unavailable

21

CLAMP

90464-99803-00

Unavailable
